Hyundai slewing bearing XKBR-00036 XKBR00036 for R80-7

Hyundai excavator Slewing motor bearing XKBR-00036

XKBR-00036 BRG.;HYUNDAI parts fit: R80-7, R80-7A, R80CR-9.



Hyundai excavator Slewing bearing XKBR-00036

P/N XKBR-00036 Material:
GCR15
i/d mm
O/D
mm
H mm
Brand: ZHZB
Precision
P0 , P6 , P5
Structure:
Tapered Roller Bearings

Product features:
1. Special bearing for excavator slewing gearbox
2. With high radial load capacity, it can also bear axial load in any direction.
3. High-strength high-quality steel
4. Long service life
5. Smooth rotation, low noise

Our advantage:
100% factory quality inspection
Respond to customer questions within one day;
Allow small orders;
Faster transportation efficiency
Good after-sales service.
Professional manufacturer of bearings for slewing gearboxes of excavators. Has many years of manufacturing experience

Production Process






Product Photos

XKBR-00036XKBR-00036XKBR-00036



※Any other parts for the Slewing motor system you need , pls search from below picture and form list then mark to me , we will quote to you.

Hyundai parts

Pos.

Part No

Qty

Parts name

Comments

*.

@

[1]

  SWING MOTOR ASSY

     4200-4211

*-1.

@

[1]

  SWING MOTOR UNIT

     4200

*-21.

31N1-10140

[1]

  SWING REDUCTION GEAR



1.

XKBR-00063

[1]

  SHAFT-DRIVE



2.

XKBR-00064

[1]

  COVER-BEARING



2.

XKBR-00094

[1]

  BEARING COVER



3.

XKBR-00036

[1]

  BEARING-TAPER ROLLER



3.

XKBR-00003

[1]

  BEARING-TAPER ROLLER



4.

XKBR-00065

[1]

  CASE



4.

XKBR-00093

[1]

  CASE



5.

XKBR-00038

[1]

  SEAL-OIL



5.

XKBR-00005

[1]

  SEAL-OIL



6.

XKBR-00039

[1]

  BEARING-TAPER ROLLER



6.

XKBR-00006

[1]

  BEARING-TAPER ROLLER



7.

XKBR-00040

[1]

  SUN GEAR NO.2



7.

XKBR-00007

[1]

  SUN GEAR NO.2



8.

XKBR-00041

[6]

  BOLT-SOCKET



8.

XKBR-00103

[6]

  BOLT-SOCKET



9.

XKBR-00042

[1]

  SUN GEAR NO.1



9.

XKBR-00102

[1]

  SUN GEAR NO.1



10.

XKBR-00066

[1]

  CARRIER ASSY NO.1



10.

XKBR-00108

[1]

  CARRIER ASSY NO.1



20.

XKBR-00069

[1]

  CARRIER NO.1



20.

XKBR-00109

[1]

  CARRIER NO.1



21.

XKBR-00052

[3]

  PLANET GEAR NO.1



21.

XKBR-00021

[3]

  GEAR-PLANET NO.1



22.

XKBR-00070

[3]

  PIN NO.1



22.

XKBR-00110

[3]

  PIN NO.1



23.

XKBR-00071

[3]

  BUSHING NO.1



23.

XKBR-00111

[3]

  BUSHING NO.1



24.

XKBR-00055

[3]

  THRUST WASHER NO.1



24.

XKBR-00112

[3]

  THRUST WASHER NO.1



25.

XKBR-00072

[1]

  THRUST WASHER NO.3



25.

XKBR-00101

[1]

  THRUST WASHER NO.3



32.

XKBR-00032

[3]

  RING-SNAP



33.

XKBR-00062

[3]

  THRUST WASHER NO.4



33.

XKBR-00113

[3]

  THRUST WASHER NO.4



11.

XKBR-00044

[1]

  GEAR-RING



11.

XKBR-00107

[1]

  GEAR-RING



12.

XKBR-00045

[1]

  CARRIER ASSY NO.2



12.

XKBR-00096

[1]

  CARRIER ASSY NO 2



26.

XKBR-00057

[3]

  THRUST WASHER NO.2



26.

XKBR-00100

[3]

  THRUST WASHER NO.2



27.

XKBR-00073

[1]

  CARRIER NO.2



27.

XKBR-00097

[1]

  CARRIER NO.2



28.

XKBR-00059

[3]

  PLANET GEAR NO.2



28.

XKBR-00028

[3]

  PLANET GEAR NO.2



29.

XKBR-00074

[3]

  PIN NO.2



29.

XKBR-00098

[3]

  PIN NO 2



30.

XKBR-00075

[3]

  BUSHING NO.2



30.

XKBR-00099

[3]

  BUSH NO.2



31.

XKBR-00031

[3]

  PIN-SPRING



13.

XKBR-00046

[2]

  PIN-DOWEL



13.

XKBR-00013

[2]

  PIN-DOWEL



14.

XKBR-00047

[1]

  COLLAR-HALF



14.

XKBR-00095

[1]

  HALF COLLAR



15.

XKBR-00015

[1]

  PLUG



15.

XKBR-00016

[1]

  PLUG



16.

XKBR-00016

[2]

  PLUG



18.

XKBR-00049

[1]

  PIPE



18.

XKBR-00105

[1]

  PIPE



19.

XKBR-00050

[1]

  GAUGE-LEVEL



19.

XKBR-00106

[1]

  LEVEL GAUGE



N.

@

[1]

  NOT SUPPLIED PARTS




Company

ZHZB Mission:We are committed to providing bearing component solutions for all construction machinery and equipment!!!

ZHZB was established in 2004 and has been committed to the development and production of engineering machinery bearings. Our products are widely used in mining equipment, road machinery, metallurgy, wind power generation, excavators and other heavy equipment and have been well received by customers!





Packaging



Delivery:

1.We will send express delivery for less than 45 kg, which is more convenient door-to-door.
2.45-200 kg we will choose air transportation, the safest, fastest, and the most expensive
3.For more than 200 kg, we will send it by sea to reduce transportation costs.



Why choose us?

  ✬1.Trusted Product


  ✬2.Advanced Technology


  ✬3.Reliable Service


  ✬4.Competitive price




FAQ

Q1: I want to buy your products, how can I pay?
A: You can contact me through Whatsapp to send bank account to you.

Q2: If we don't find what we want on your website, what should we do?
A: You can email or Whatsapp us the descriptions and pictures of the products you need, we will check whether we have them. We develop new items every month. and some of them have not been uploaded to website in time. Or you can send us sample by express, we will develop this item for bulk purchasing.

Q3: Can we buy 1 pc of each item for quality testing?
A: Yes, we are glad to send lpc for quality testing if we have the item you need in stock
