Hyundai spare parts XKAQ-00027 XKAQ00027 for R330LC9A

Hyundai excavator Slewing motor spare parts XKAQ-00027 XKAQ00027


XKAQ-00027 BRG.;HYUNDAI parts fit: R290LC7, R290LC7A, R290LC7H, R290LC9, R290LC9MH, R300LC7, R300LC9A, R300LC9S, R300LC9SH, R305LC7, R320LC7, R320LC7A, R320LC9, R330LC9A, R330LC9S, R330LC9SH, R360LC7, R360LC7A, R360LC9 .




Hyundai excavator Slewing bearing XKAQ-00027

P/N XKAQ-00027 Material:
GCR15
i/d mm
O/D
mm
H mm
Brand: ZHZB
Precision
P0 , P6 , P5
Structure:
Spherical roller bearing

Product features:
1. Special bearing for excavator slewing gearbox
2. With high radial load capacity, it can also bear axial load in any direction.
3. High-strength high-quality steel
4. Long service life
5. Smooth rotation, low noise

Our advantage:
100% factory quality inspection
Respond to customer questions within one day;
Allow small orders;
Faster transportation efficiency
Good after-sales service.
Professional manufacturer of bearings for slewing gearboxes of excavators. Has many years of manufacturing experience

Production Process






Product Photos

XKAQ-00027Hyundai XKAQ-00027Bearing XKAQ-00027



Any other parts for the Slewing motor system you need , pls search from below picture and form list then mark to me , we will quote to you.

Hyundai parts


Pos.

Part No

Qty

Parts name

Comments

*-2.

31Q8-10140

[1]

  SWING REDUCTION GEAR

     SEE 4100

*-2.

31Q8-10141

[1]

  SWING REDUCTION GEAR

     SEE 4100

*-2.

31Q8-10142

[1]

  SWING REDUCTION GEAR

     SEE 4101

*-2.

31Q8-10142AR

[1]

  SWING REDUCTION GEAR

     SEE 4101

1.

XKAQ-00451

[1]

  CASING



2.

XKAQ-00452

[1]

  SHAFT-DRIVE



2.

XKAQ-00760

[1]

  SHAFT-DRIVE



3.

XKAQ-00146

[1]

  BEARING-ROLLER



4.

XKAQ-00149

[1]

  SEAL-OIL



5.

XKAQ-00027

[1]

  BEARING-ROLLER



6.

XKAQ-00467

[1]

  CARRIER ASSY 2



7.

XKAQ-00468

[1]

  CARRIER 2



8.

XKAQ-00469

[4]

  GEAR-PLANET 2



9.

XKAQ-00470

[4]

  PIN ASSY 2



N10.

XKAQ-00471

[1]

  PIN 2



N11.

XKAQ-00472

[1]

  BUSHING 2



12.

XKAQ-00435

[8]

  WASHER-THRUST



13.

XKAQ-00050

[4]

  PIN-SPRING



14.

XKAQ-00473

[1]

  CARRIER ASSY 1



15.

XKAQ-00453

[1]

  CARRIER 1



16.

XKAQ-00454

[3]

  GEAR-PLANET 1



17.

XKAQ-00440

[3]

  PIN ASSY 1



N18.

XKAQ-00441

[3]

  PIN 1



N19.

XKAQ-00079

[3]

  BUSHING 1



20.

XKAQ-00417

[3]

  PLATE 1-SIDE



21.

XKAQ-00416

[3]

  PLATE 2-SIDE



22.

XKAQ-00041

[3]

  RING-STOP



23.

XKAQ-00048

[3]

  PIN-SPRING



24.

XKAQ-00455

[1]

  GEAR 2-SUN



25.

XKAQ-00456

[1]

  GEAR 1-SUN



26.

XKAQ-00457

[1]

  RING-GEAR



27.

XKAQ-00466

[12]

  BOLT-SOCKET



28.

XKAQ-00626

[1]

  COVER PLATE



29.

XKAQ-00064

[8]

  BOLT-HEX



30.

XKAQ-00627

[1]

  SPACER



31.

XKAQ-00628

[1]

  RING-SPACER



32.

XKAQ-00447

[1]

  PLATE 3-THRUST



33.

XKAQ-00629

[1]

  GEAR-PINION



34.

XKAQ-00630

[1]

  PLATE-LOCK



34.

XKAQ-00761

[1]

  PLATE-LOCK



35.

XKAQ-00042

[2]

  BOLT-HEX



35.

XKAQ-00756

[4]

  BOLT-HEX



36.

XKAQ-00292

[1]

  WASHER-LOCK



37.

XKAQ-00049

[1]

  PLUG



38.

XKAQ-00066

[2]

  PLUG



39.

XKAQ-00035

[1]

  PIPE-GAUGE



40.

XKAQ-00034

[1]

  BAR-GAUGE



40.

XKAQ-00985

[1]

  BAR-GAUGE



41.

XKAQ-00072

[2]

  PIN-KNOCK



42.

XKAQ-00143

[1]

  POST-AIR BREATHER

     NOT USED

42.

XKAQ-00800

[1]

  AIR BREATHER ASSY



N43.

XKAQ-00631

[4]

  BUSHING 2



N.

@

[AR]

  NOT SUPPLIED PARTS
