– Channel Architecture in One Glance
|
Channel Talent
|
Why it Matters
|
|
40× TMR inputs, 3-way vote
|
Single fault = 0 % data loss
|
|
0–22 mA sink range
|
Covers legacy 4–20 mA + over-range tests
|
|
2500 V impulse isolation
|
Surge-proof up to 5 × industrial mains spike
|
|
1 ms SOE stamp per change
|
Forensic-level trip replay
|
|
Cable break & short hunter
|
Per-channel line-monitor, no extra dongles
|
– “SmartSlot, Zero Downtime”
Hot-replacement without a spare TMR rack: use one Companion slot or a single SmartSlot as a shared parking bay for any Trusted AI module. Module automatically inherits tag-names & thresholds < 5 s after insertion—no re-download from engineering station .
– “Paint-Coat Secret”
Optional factory CCoat variant (same part-number suffix) adds 25 µm polyurethane conformal layer. Salt-spray resistance jumps from 48 h to 1000 h (ASTM B117), making T8431C eligible for offshore wellhead platforms without extra cabinet sealing.
– “LED Language”
Front-panel light guide gives pixel-free visibility even under UV-heavy control rooms:
1. Green steady = Active voter winning
2. Orange blink 1 Hz = Standby voter, healthy
3. Red 2 Hz = Field wiring fault (open/short)
4. Red 4 Hz = Module internal dissent, needs swap
No handheld diagnostic required—status readable from 6 m away.
– “Thermocouple Whisperer”
Hidden gem: each channel can be re-mapped to ±80 mV differential, letting you land J/K/E-type thermocouples directly—no external cold-junction box. On-board ice-point compensation accuracy ±0.5 °C, update 0.5 ms, resolution 3.9 µV .
– “Certification Stack”
TÜV Rheinland IEC 61508 SIL 3 (Type A) + IEC 61131-2 + ABS Marine + CE & UKCA. One module, four industries certified out-of-box: process, power, marine, machinery.
– “Dimensional Freedom”
266 mm H × 31 mm W × 303 mm D = 9 HP width. Slide two side-by-side in a 19″ sub-rack and you still have 1 HP free for a future DO module—no blanking plate needed.
