1. Module at a Glance
T9432 brings 16 differential analogue channels into the AADvance® SIL-rated architecture. Each channel is independently configurable for 0-20 mA, 4-20 mA, 0-5 V or 1-5 V and provides open-wire, short-circuit and over-range diagnostics. 16-bit Σ-Δ A/D + triple-sample voting deliver <0.1 % span accuracy while still fitting a single 19-inch slot.
Stand-out points
· 16 × universal AI, loop-powered or self-powered
· SIL 3 capable, certified to IEC 61508 (Type B)
· Automatic line-monitoring – no extra field resistors
· 3-way galvanic isolation (channel ↔ bus ↔ power)
· -40 °C … +70 °C full-spec, hot-swap enabled
2. Channel Map & Factory Defaults
|
Slot
|
Default Range
|
Live-wire Detect
|
Burn-out Direction
|
|
0-3
|
4-20 mA
|
Enabled
|
Upscale (24 mA)
|
|
4-7
|
0-5 V
|
Disabled
|
Downscale (0 mA)
|
|
8-11
|
1-5 V
|
Enabled
|
Upscale
|
|
12-15
|
4-20 mA
|
Enabled
|
Upscale
|
3. Accuracy vs. Temperature Chart
|
Range
|
25 °C Accuracy*
|
-40 °C Drift
|
+70 °C Drift
|
Max Loop Impedance
|
|
4-20 mA
|
±0.05 %
|
+0.02 %
|
-0.03 %
|
750 Ω
|
|
0-5 V
|
±0.08 %
|
+0.04 %
|
-0.05 %
|
10 kΩ
|
|
1-5 V
|
±0.07 %
|
+0.03 %
|
-0.04 %
|
10 kΩ
|
4. Ordering & Logistics Benefits
PLC Autocontroller keeps genuine T9432 units on the shelf in Xiamen.
· Original ICS-TRIPLEX sealed anti-static trays
· One-year replacement warranty
· Same-day collection after payment confirmation
· Worldwide express: DHL, FedEx, UPS, TNT – customs paperwork included
24 h quotation window – send your RFQ to ab@mooreplc.com
