Key strengths
1. 40 differential pairs, individually foil-shielded → 120 dB crosstalk rejection @ 1 MHz
2. Megamide braided sheath → oil- & coolant-resistant, lay it on the fab floor
3. V2 latching → 30° lead-in, clicks home even when you can’t see the connector
4. -40 … +85 °C rating → topside rigs or desert wells, same cable
5. Dual UL AWM 20233 & IEC 61010 approval → one certificate covers any project site
Quick-look pin-out
|
End
|
Connector
|
Pins
|
Example pair
|
Note
|
|
SmartSlot
|
96-way Type-C
|
1-96
|
WH/OG diff +
|
metal shell earthed
|
|
Module
|
96-way Type-R
|
1-96
|
OG diff –
|
polarised key
|
|
Shield
|
360° clamp
|
—
|
bare copper
|
factory-crimped, no field stripping
|
Sibling cables at a glance
|
Part number
|
Channels
|
What’s different
|
When to pick it
|
|
TC-501-02-2M5
|
40 Ch Input
|
2 m length
|
side-by-side racks, neater run
|
|
TC-502-02-4M5
|
40 Ch Output
|
built for output modules
|
drives valves, relays; pin-out mirrors TC-501
|
|
TC-506-02-4M5
|
60 Ch Input
|
higher density
|
wire dozens of RTDs or wells in one move, fewer FTAs
|
All share V2 latches and Megamide sheath—mix and match on the same tray with no extra tooling.
