Industrial-Grade Modular Long-Endurance Multi-Rotor Drone

       The Y-726 multi-rotor drone features a body made of high-strength composite materials, which is lightweight, sturdy, wind-resistant and rain-proof, to make it suitable for long-term outdoor operations. The advanced flight control system enables centimeter-level hovering and autonomous route planning, and supports multiple safety strategies such as one-click return and low-battery return, and lowers the operational threshold. The high-definition pan-tilt camera is combined with three-axis mechanical stabilization. It can output stable and smooth images day and night, and provide precise visual support for industries such as inspection, mapping, and search and rescue. The modular battery and quick-release structure make maintenance simpler and significantly reduce the operation preparation time. The open mounting interface can flexibly carry various task devices such as loudspeakers, searchlights, and gas detectors, meeting the needs of diverse scenarios.











Product features



Simple structure, folding boom, small transportation volume



Long battery life, plug-and-pull design for easy replacement



Dual-antenna RTK, centimeter-level positioning and orientation



Forward obstacle avoidance function, enhancing the safety factor





Technical indicators





Y-726 type

Expanded size

738*673*425mm(excluding blades)

Folding size

428*412*425mm(including blades)

Wheelbase

900mm

Fuselage material

High-strength engineering plastics, aviation aluminum materials

Boom folding method

Horizontal folding

Empty drone weight

4.7kg(not including battery)

No-load weight

8.4kg(including battery)

Maximum takeoff weight

10.5kg

Maximum ascending speed

4m/s

Maximum descent velocity

2m/s

Maximum horizontal flight speed

20m/s

Maximum flight altitude

5000m

Protection grade

IPX4

Wind resistance capacity

11.5m/s

Flashing light frequency

1.5HZ

FPV camera

Field of view (FOV) : 122 degrees horizontally, 113 degrees vertically

Controllable pitch rotation Angle: 68 degrees

FPV camera recording

Support 4K card recording

FPV mode

Pitch follow mode +FPV mode

Working voltage

12S* Maximum voltage 53.4V

Battery type

Intelligent battery

Battery compartment size

215mm*144mm*80mm

Mounting installation method

Front and rear expansion ports

Obstacle avoidance

Obstacle avoidance types

LIDAR obstacle avoidance

Obstacle avoidance direction

Forward view

Obstacle avoidance range

Forward view: 0.1m to 12m

Obstacle avoidance speed

8m/s

Anti-light intensity of LIDAR

70Klux

Obstacle avoidance field of view Angle

3.6°

Battery capacity

17000mAh

Battery weight

Around 3.7kg

No-load battery life

Around 55min

Full-load battery life

Around 43min

Maximum control distance

35km(no interference and obstruction)

The above parameters are for reference only. The detailed product parameters are subject to the actual delivery.
