Specification

LIGHT SOURCE

Lamp: Philips 330W or superior YODN 350W lamp

CT: 8000 K

Lifespan: 2,000H

OPTICS

Beam angle: 1.5°~3°

Yilong optical system

Improved optics and flat beam field

COLORS

1 Color wheel: 13 color+open

Half-color effect, linear color change, bidirectional rotating rainbow effect

GOBOS

1 Static gobo: 17 gobos(3 glass gobo)+open, shakable and bi-directionally rotatable at variable speeds

MOVEMENT
Pan movement: 540° optional (16 bit )

Tilt movement: 270°(16 bit )
Advanced moving system: auto repositioning, fast, quiet and smooth

FEATURES

2 Prisms: 8-facet+16-facet, bi-directionally rotatable at variable speeds

Frost: 1 frost filter, soft and natural wash effect

Strobe: mechanical shutter , variable from 1-13Hz or random
Dimming: mechanical dimmer 0-100% linearly adjustable

Focus: motorized linear focus

Housing: all PV+fiber plastic housing

Protection rate: IP65

DISPLAY

2.8 inch full color touch LCD screen, sensor key

SOFTWARE

Control mode: DMX512, master-slave, auto-run, sound activate

Channel: 35CH

Run time of lamp and fixture record

OTHER SPEC

Fixture and lamp usage time display

Highly positioning precision

Input signal isolating protection

Auto thermal protection circuit

POWER
Voltage: AC100-240V, 50/60Hz

Power Consumption: 600W@220V

DIMENSIONS AND WEIGHT

Fixture dimension: 46*32*67cm

Packing dimension:

                         48x40x75cm (Carton)

                         52x43x80m(1 in 1 flightcase)

Net Weight:         30kg

Gross Weight:

                         32kg(Carton)

                         55kg(1 in 1 flightcase)
