Customized ISUZU Guardrail Cleaning Trucks
Introduction
ISUZU Guardrail Fence clean washing Truck (also
called ISUZU Truck mounted guardrail cleaning truck, Street guardrail washing truck) Use Automatic control system,electric/gas system,hydraulic system central contril,easy operation, all can be operated in cabin by driverć
Our Isuzu Guardrail cleaning vehicle with clean device in the front of left side,both side can clean, 4 sets of rolling brush tight the guard bar and rolling to clean, washed by high pressure water,electric hydraulic type is used for isolation barrier; Use hydraulic telescopic boom to clean, main boom can lift up and down, brush boom can telescopic front and back to guarantee the clean efficiency.
Advantages
|
|
100% custom-made
|
|
|
3 cbm to 22 cbm available
|
|
|
Short delivery time 7~30 days
|
|
|
Easy operation & Easy maintenance
|
|
|
15 years spare parts & Technical support
|
Main Parameters
|
Manufacturer
|
PowerStar Trucks Industry Co., Limited
|
|
Product Name
|
ISUZU Guardrail washing trucks
|
|
Vehicle Brand Series
|
ISUZU
|
|
Vehicle Model
|
PST5070GQX
|
|
Production Time
|
25 days
|
|
Chassis parameters
|
Overall dimensions
|
mm
|
7160*2300*2860
|
|
Gross weight
|
kg
|
7,300
|
|
Kerb weight
|
4,760
|
|
Wheelbase
|
mm
|
4,175
|
|
Driving type
|
4*2
|
|
Chassis model
|
ISUZU GIGA Heavy-duty
|
|
Tire size
|
10.00-20-16PR
|
|
Number of Tires
|
6+1
|
|
Passengers in cab
|
3
|
|
Engine
|
Engine model
|
6UZ1-TCG50
|
|
Type of fuel
|
Diesel
|
|
Power
|
380HP
|
|
Max speed
|
Km/h
|
95
|
|
Emission standard
|
EURO 4,5,6
|
|
Water Tanker performance
|
Tanker Body
|
5,000L
|
|
Body Material
|
Weather Resisting Steel
|
|
Tanker Shape
|
Ellipse as standard
|
|
Water Pump
|
China Famous Brand 50m3/h
|
|
Optional Italy, Euro brand
|
|
Minimum working speed
|
4 km/h
|
|
Cleaning height
|
120~1400 mm
|
|
Cleaning width
|
0~200 mm
|
|
Cleaning efficiency
|
ā„95
|
|
Hose & Hose-carrier
|
Factory standard
|
|
Control Panel
|
English
|
|
Walkway and Hand rail
|
Yes
|
|
Painting
|
Two primers, and one final paint coating
|
|
Color & LOGO
|
According to wish
|
|
Factory standard
|
āUā shape
Sub Frame, Hydraulic system, Ejector panel, Safety protection, Rotating Lamp,
Working Lamp, Hand holds, Mudguards and rubber flaps...
|
|
Documents
|
English
operation manual, Spare parts list, and all necessary export docs.
|
|
Optional equipment
|
1, Stainless steel tank, Aluminum alloy tank
2, Wider platform and Fire Cannon
3, Electricity controlled separately sprinkler
4, Spreading salt water * Snow-melting agent
|
Key words: GIGA Water Bowser, Isuzu Water spray tanker truck, GIGA Isuzu sprinkler
