CPU
|
ARM Dual core, CortexA9,1.5GHZ
|
|
Screen Size
|
15＂
|
|
Resolution
|
1024*768
|
|
Brightness
|
200nit
|
|
Contrast
|
450:01:00
|
|
Active Area (mm)
|
0.240 X 0.240
|
|
Viewing angle
|
246°(H) 184.5°(V)
|
|
Response time
|
40ms
|
|
RAM
|
DDR3 1GB
|
|
Internal storage
|
4GB/8GB/16GB/32GB(OPTION)
|
|
WIFI
|
Wi-Fi802.11/b/g/h
|
|
Bluetooth
|
Yes
|
|
Interface
|
4xUSB2.0 ,1x10/100M self-adaption RJ45 interface ,1xUSB2.0
|
|
OTG, 1xHDMI, 1xaudio port
|
|
Touch screen
|
Capacitive Touch screen .
|
|
Serial ports
|
2xSerial ports
|
|
OS
|
Android 4.4.2
|
|
Camera
|
Built-in 5,000,000 pixel
|
|
TF Card
|
Yes
|
|
Microphone
|
Yes
|
|
Frequency
|
Built-in 2W loudspeaker
|
|
Built-in (optional)
|
2xUSB2.0, POE power supply, keyboard port, 4xI/O ports, 1xI2C, LVDS port
|
|
Signal Input Video:
|
Analog Signal/ Sync: TTL
|
|
Audio Out
|
2x2W(optional)
|
|
1080P/ 3D video output
|
Support
|
|
Power
|
≤15W
|
|
Video format(1080P)
|
WMV,MKV,MOV,AVI,RM/RMVB,MPEG-2/4.
|
|
Audio format
|
MP3,WMA,3GP,AAC,FLAC,WAV.OGG
|
|
Card reader
|
Optional
|
|
Fittings
|
Signal Line Power Adapter Audio Line
|
|
Outer carton dimension
|
420*170*415mm
|
|
Weight
|
6.4KG
|
|
Color
|
Black/White
|
