Juniper Compatible XFP BIDI 1490/1550nm 100km 10G Bidirectional Fiber Optic Transceiver

TOPSTAR's TOP-BIDI-XFP-100A/B transceivers are designed for 10G Ethernet 10G BASE-LR/LW per 802.3ae and 10G SOI OC-192/SDH STM-64, and it can support data-rate from 9.953Gb/s to 11.1Gb/s. Digital diagnostics are avail-able via I2C interface as specified in the XFP MSA. The transceiver designs are optimized for high performance and cost effective to supply customers the best solutions for data-com and telecom applications.


  • Distance100km
  • Data Rate10G
  • Temperature 0℃~70℃/ -5℃~85℃/ -20℃~85℃
  • ConditionNew
  • Warranty3 Years
  • Wavelength1490/1550nm
  • ConnectorLC

Juniper Compatible XFP BIDI 1490/1550nm 100km 10G Bidirectional Fiber Optic Transceiver

SMF 10G SFP+ EZR 1550nm Ultra Long 100km Transceiver

10G SFP+ EZR 1550nm Transceiver



PRODUCT FEATURES

XFP MSA package with single LC connector

Typical bidi 1490/1550nm and 1550nm/1490nm for commission

APD receiver for high sensitivity

Hot pluggable

Support 9.95Gb/s to 11.1Gb/s bit rates

Digital Diagnostic Monitor Interface

Very low EMI and excellent ESD protection

+3.3V single power supply

Below <1.5w power consumption

operating temperature range 0°C to 70°C

No reference clock requirement


APPLICATIONS

10GBASE-BX 10.3125Gb/s Ethernet

10GBASE-BX 9.953Gb/s Ethernet

SONET OC-192 &SDH STM I-64.1


STANDARD

XFP MSA Compliant

SFF-8472 reversion 9.5 compliant

IEEE802.3-2005 compliant

Telcordia GR-468-CORE compliant

FCC 47 CFR Part 15,Class B compliant

FDA 21 CFR 1040.10 and 1040.11,class1 compliant

RoHS compliant


Professional Service

Fully testing in Error Detector/ Industrial Oven/ Agilent Oscilloscope/ Digitizer/ WaveRunner etc specialist testing equipment before shipment.

Compatibility:

Testing in Cisco/ Brocade/ Juniper/ Dell/ Arista/ HPE/ H3C etc devices to guarantee 100% compatible with your equipment.


OEM& ODM:

Customized label and package , OEM and ODM service offered




Product Tags xfp bidi          xfp 10g bidi          bidi xfp lr          xfp bidi 20km          bidi xfp module          10g xfp bidi 60km          10g xfp bidi 40km          10g xfp bidi 10km          Cisco XFP BIDI 60km
