Introduction
The lithium ironphosphate (Lifepo 4 ) is a type ofrechargeable battery based on the orriginal lithium ion chemistry ,created by the use of Iron (FE ) as a cathode material.
LiFePo4 cells have higher discharge current do not explode under extreme conditions and wegh less but have lower voltage and energy density than normal Li-lion cells.
Quick details:
Good high temperature performance
Safe Lithium Iron Phosphate Technology
High energy density and conversion efficiency
Life Span: 1000 cycle times
Environmental Friendly, without any heavy metals
Complete with Battery Management System built-in
Can use AC and solar chargers for this system
Low self discharge rate
Easy installation, can be in standard cabinet or be wall-mounted
Built-in automatic protectionfor over-charge, over-discharge&over-temperature conditions
High energy density 120-130kwh/kg,evenhigh discharge rate , while maintaining high energy capacity.
Increased Flexibility : Modular design enables deployment
Good High Rate Discharging and Excellent Stability
Intelligent chip design, excellent battery's storage capacity
|
Item
|
Specification
|
|
Type
|
lithium battery
|
|
Voltage
|
48V
|
Rated capacity
|
100Ah (0.2C/25°C) (Min:98Ah)
|
Energy
|
4200wh
|
Operating voltage range
|
42V- 58.4V (Typical:51.2V)
|
Charging voltage
|
56.0V±1.0V
|
Discharge cut-off voltage
|
42V±2.0V
|
Charging current
|
20A
|
Charging current(Max.)
|
30A
|
Continuous Current
|
50A
|
Discharge current(Max.)
|
100A
|
Months Self Discharge
|
≤3.5%
|
