N-BK7 and Fused Silica Wedge Prisms

Wedge prism is an optical element with plane-inclined surfaces, usually the faces are inclined toward one another at a very small angles.  It diverts light toward its thicker portion.  Wedge prisms can be used as isolating components. Wedges may also be used to produce a small deviation which doesnt allow return to source.



1. What is wedge prism used for?



Wedge prism is an optical element with plane-inclined surfaces, usually the surfaces are inclined toward one another at a very small angles. It diverts light toward its thicker portion. Wedge prisms can be used as isolating components. Wedges may also be used to produce a small deviation which doesn’t allow return to source.



2.What kinds of materials can UNI Optics use to make right angle prism?



N-BK7, Grade A optical glass, Fused silica



3. What is UNI Optics regular manufacturing capability for wedge prism?


Wedges Prisms  Wedge Prisms


Specification

Standard capability

Dimensional Tolerance

+/-0.1mm

Wedge Tolerance

+/-0.1mm

Flatness

λ/4@632.8nm

Surface Quality

60-40

Coating: Optional

Bevel: protective



4. What is the typical size?



Part No.

Diameter

Material

Deviation

Wedge

T(mm)







angle(α)

angle(β)

Thickest

UWGA001

Φ25.4

N-BK7

1°57

3.86

UWGA002

Φ25.4

N-BK7

3°53

4.72

UWGA003

Φ25.4

N-BK7

7°41

6.43

UWGA004

Φ25.4

N-BK7

11°21

8.11

UWGA005

Φ25.4

N-BK7

14°51

9.74

UWGA006

Φ25.4

N-BK7

10°

18°08

11.33

UWGJ001

Φ25.4

JGS1

2°4

3.88

UWGJ002

Φ25.4

JGS1

4°7

4.78

UWGJ003

Φ25.4

JGS1

8°14

6.57

UWGJ004

Φ25.4

JGS1

12°21

8.4
