PERFORMANCE PARAMETERS
|
|
Light Source
|
Visible Laser Diode 650nm
|
|
Line
|
20Lines
|
|
Scan Rate
|
1380±5% Lines / Second
|
|
Scan Pattern
|
Omnidirectional:5Fileds of 4 parallel lines
|
|
Print Contrast
|
30% minimum reflectance difference
|
|
Decode Capability
|
EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN 128, ISBN,ISSN, Codabar, Code 25 non-interleaved, Code 25 interleaved , Matrix 2 of 5, MSI, PostBarcode, etc
|
|
ELECTRICAL PARAMETERS
|
|
Support Interface
|
PS/2, USB,RS232
|
|
Voltage .Power
|
5VCD±12% 1.6W
|
|
Laser-level
|
Class1:IEC60825-1
|
|
EMC
|
FCC part 15class B,CE En55022B,VCCI,BSMI
|
|
LED Indicator
|
Red and Blue
|
|
PHYSICAL PARAMETERS
|
|
Weight (pcs)
|
N.W: 474g/pcs G.W: 768g/pcs
|
|
Size (pcs)
|
Host: 115mm*110mm*152mm Package: 245mm x165mmx132mm
|
|
Weight (Carton)
|
9.6 kg/10pcs
|
|
Package
|
|
Size (Carton)
|
680mm*350mm*280mm
|
|
ENVIRONMENTAL PATAMETER
|
|
Crash resistant
|
Can withstand 1.5M free fall
|
|
Operating
|
0Degrees to 40 Degrees (32Fahrenheit to 104 Fahrenheit)
|
|
Storage Temperature
|
-20 Degrees to 40 Degrees (-4 Fahrenheit to 104 Fahrenheit)
|
|
Humidity
|
5% to 95% Relative humidity, Non-condensing
|
|
Environmental
|
Sealed to resist airborne particulate contaminants
|
The third generation, Barcode Scanner with perfect scanning process. Barcode scanner with the fastest speed ( Explosive ) and top-level, performance. Different bar codes ( colorful / vacuum packing / blur / crumpled / reflective ) can be read easily.
Invention highlight I : Barcode Suture Technique, (Damged Code ) Signal recognition Restructuring . Deformation, crumpled code can be read easily.
Invention highlight II : Dual signal automatic error correction techniques. colorful , blur, vacuous, reflective barcode swept away
Invention highlight III : Intelligent Identification memory. Recognize and remember barcode type and quality automatically while scanning. , Decoding speed can improve 30% while read again.
|
