Original 9405W-16e hba card 05-50044-00 SFF-8644 12Gb/s SAS SATA NVMe Tri-Mode HBAs

12Gb/s SAS/SATA/PCIe (NVMe) Tri-Mode HBAs
Model 9405W-16e
PN 05-50044-00
I/O SAS3616W
Device Support SAS/SATA: 1024, NVMe: 24
Warranty 3 Years

Facebook Twitter Pinterest LinkedIn 分享
9405W-16E HBA card 05-50044-00 for server
Applications
• Ideal for bandwidth-intense applications such as UHD and big data analytics
• Tri-Mode connectivity enabling maximum data center flexibility
• Highest sequential throughput; ideal for video streaming, big data analytics, medical imaging and media applications
• High bandwidth storage to SAS, SATA, or NVMe devices
Key Features
• x16 PCIe 3.1 Host Interface
  − Supports x16, x8, x4, x2, x1 PCIe lanes at a transfer rate up to 8.0 GT/s per lane, full duplex
  − Lane and polarity reversal
  − Variable PCIe bandwidth negotiation
• Low Profile MD2 Form Factor
• Tri-Mode enabled external storage interface
• Supports 12Gb/s SAS, 6Gb/s SATA, and PCIe (NVMe) up to 8.0 GT/s
Specification
Model 9405W-16e
Ports 16 external
PN 05-50044-00
Connectors Four (x4) SFF-8644
Storage Interface SAS, SATA, PCIe (NVMe)
I/O Processor/ SAS  Controller SAS3616W
Max Devices Per Controller
 SAS/SATA: 1024, NVMe: 24
Host Interface PCIe 3.1 x16
Cable Support
 Passive copper, active copper, active optical
Typical Power 14.0W
Physical Dimensions 6.127” x 2.712”

Lead time

Quantity (pieces) 1-10 10-60 >60
Lead time (days) 3 3-5 To be negotiated
