Key Features
• LSI SAS 3108 8-port PCI-E SAS-3 controller
• 8-port (8 internal) 12Gb/s per port
• Supports RAID 0, 1, 5, 6, 10, 50, 60
• On board hardware IO Processor
• 2GB 1866MHz DDR3 on-card cache
• Advanced array configuration and management utilities
• Automatically negotiates PCI-E link widths
• Power management support
• Supports 1.5, 3.0, 6.0 and 12Gb/s SAS and SATA data transfer rates
• Port independent auto-negotiation
• Supports SSP, SMP, STP and SATA protocols
• Optional Supercap/TFM Unit for cached data protection (BTR-TFM8G-LSICVM02) - operating temperature (Ambient) from 10°C - 55°C
• OS Support : Windows 2012, 2k8 64/32 bit, RedHat Enterprise and SUSE Linux
Specification
|
Model
|
AOC-S3108L-H8IR
|
|
IO controller
|
LSI SAS 3108
|
|
Number of internal ports
|
4
|
|
Directly serviced SAS drives
|
8
|
|
Directly serviced SATA drives
|
8
|
|
Raid levels
|
0, 1, 5, 6, 10, 50, 60
|
|
Type
|
SAS3
|
|
Availability
|
In Stock
|
Lead time
| Quantity (pieces) |
1-10 |
10-60 |
>60 |
| Lead time (days) |
3 |
3-5 |
To be negotiated |
About Us
STOR TECHNOLOGY LIMITED founded in 2007, focusing on providing hardware solutions for cloud computing ,cloud storage,data centre, security monitor, customized server and other fields. Our main products are Raid Card, HBA Card,Fiber Card,Network Card,Hard Drives,CPU. We can provide long-term good after sales service for customers. ODM orders Welcome!
Our Advantages
FAQ
Q1: What payment method do you accept?
A1: Trade assurance, T/T, Western Union
Q2: What is the mininum order Quantity(MOQ）?
A2: We can sell one piece for testing.
Q3: When is the lead time of your products?
A3: we have stock, we can provide fast delivery within 2~3 days for 10pcs.
Q4: How about the warranty service?
A4: 3 year for wanrranty free.
