Outdoor Aluminum Sports Canopy Tent
Sports Canopy Tent's Advantage:
1. Popular shaped tent for all events.
2. Weather resistant with keder tracked tops and sidewalls.
3. Easy to integrate heating and A/C.
4. Roof and gable vent is available.
5. A variety of accessories available for customization.
Sports Canopy Tent's's Available sizes:
● Clear span available from 3m to 60m.
● Length: adjustable by 3m unit (SS & WS series) or 5m unit (for other series).
Sports Canopy Tent's Features:
● No exterior guy ropes or staking required.
● No poles inside, 100% interior space be used.
● Roof and gable vent is available.
● Relocatable, easy to install, dismantle and transport.
● Full line accessories available.
Sports Canopy Tent's Frame:
● No maintenance required.
● Extruded 4 channel aluminum hollow profiles with anodized finishing above 12um.
● All steel connectors including small parts have galvanized finishing above 60um.
● Modular character for diverse combination and expansion.
Sports Canopy Tent's Cover:
● Kedered roof fabric and sidewalls provide weather-proof tight coverings.
● Bar tensioning roof & sidewalls system.
● Different brand fabric for option: China Fabric, Ferrari, Sioen, Verseidag.
|
Type
|
Span (m)
|
Side height (m)
|
Ridge height (m)
|
Bay Distance (m)
|
Roof Pitch
|
Longest Component (m)
|
Wind Load (km/h)
|
|
WS6/3-3
|
6
|
3
|
4.1
|
3
|
20°
|
3.5
|
80
|
|
WS9/3-3
|
9
|
3
|
4.6
|
3
|
20°
|
4.9
|
80
|
|
WS10/3-3
|
10
|
3
|
5.1
|
3
|
20°
|
6.5
|
80
|
|
WS15/3-3
|
15
|
3
|
5.6
|
3
|
20°
|
8.1
|
80
|
|
Main frame Profile
|
122x68x3mm（4-channel)
|
|
Eave Connection
|
Hot-dip Galvanized Steel Insert
|
|
Roof Fixing
|
Bar Tension
|
|
Frame Material
|
Hard Pressed Extruded Aluminum 6061/T6
|
|
Cover Material
|
Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,650-900g/sq.m
|
