advanced core patented technology
|
|
high safety, triple anti-pinch
|
|
high stability, optimize the mechanism structure
|
|
long life, longer than 10 million times
|
|
|
|
|
|
|
|
|
|
accurate & fast detection
|
|
high visitor flow rate usage
|
|
modular design, easy maintenance
|
|
high compatibility, high integration
|
Advanced & Intelligent Turnstile Core Technology
Advanced core logic algorithm
The speed gate turnstile adopts CMOLO® patented passing detection algorithm and matrix photoelectric stereo detection technology, to sensitively detect illegal behaviors such as reversely passing and tailgating, and issues warnings in the form of sound and light, and can be linked with other security systems.
Advanced motor control technology
The turnstile adopts advanced servo control system, DSP+ARM motor control technology, combined with CMOLO's original motor control algorithm, to achieve precise control and positioning of the obstacles and maintain stable performance.
Strong mechanism structure
CMOLO has independently developed an advanced lossless mechanism structure, and is equipped with industrial grade brushless servo motor (core of the mechanism), so that the pedestrian speed gate turnstile has a long service life.
Long service life
The speed gate turnstile's mechanism & control system have passed 5 million times life test.
All-around Pedestrian Safety Protection
Triple anti-clamping
With triple anti-clamping technologies such as infrared anti-clamping, mechanical anti-clamping and anti-collision by advanced electric current detection, speed gate turnstile can protect pedestrian safety more comprehensively.
Over-force feedback control
When the speed gate turnstile is momentarily subjected to an impact force beyond the safe range, the gate can be slowly pushed for a certain distance to buffer the impact force on the mechanism and the reverse impact force on pedestrians.
Anti-electric shock
All electric modules are designed to operate under the safety voltage of 24V, and configured with residual current protective device to prevent pedestrian from being injured by electric shocks.
Turnstile opens when power failure
With the independently developed advanced mechanical structure, the system will automatically unlock the gate when the power is off, and the gate can be manually pushed to open, which is convenient for pedestrian evacuation.
Emergency open
The speed gate turnstile equips with emergency escape control device, to make the system automatically open the gate to evacuate pedestrian.
Customization
| Appearance |
Cabinet size, material and surface treatment process etc. of turnstile can be moderately customized. |
| Lane width |
The maximum lane width of turnstile is 900mm, and the cabinet length can be increased accordingly |
| System integration |
Integrate with access control system, human body temperature measurement system, ticketing system, time attendance system, visitor system etc.
Integrate with QR code, face, fingerprint, ID/IC card, passport identification system etc.
Integrate with card collection system, and customize card collection device
|
