Features
- Design and fabrication compliant with API Spec. Q1, 4F, 7K, 8C and API monogrammed.
- Modular design achieves fast move and transportation.
- Mechanical transmission, simple operation and easy maintenance.
- Special oilfield off-road chassis extends service life.
Specifications
|
Model
|
XJ700
|
XJ900
|
XJ1100
|
XJ1350
|
XJ1600
|
XJ1800
|
XJ2250
|
|
Max. hook load, kN(lb)
|
700 (160,000)
|
900 (200,000)
|
1100 (250,000)
|
1350 (300,000)
|
1600 (360,000)
|
1800 (400,000)
|
2250 (500,000)
|
|
Rated hook load, kN(lb)
|
400 (900,000)
|
600 (130,000)
|
800 (180,000)
|
1000 (225,000)
|
1200 (270,000)
|
1500 (337,000)
|
1800 (400,000)
|
|
Service depth with 73mm (2 3/8) TBG, m(ft)
|
3200 (10500)
|
4000 (13100)
|
5500 (18000)
|
7000 (23000)
|
8500 (27900)
|
-
|
-
|
|
Workover depth with 73mm(2 3/8) DP, m(ft)
|
2000 (6560)
|
3200 (10500)
|
4500 (14800)
|
5800 (19000)
|
7000 (23000)
|
8000 (26200)
|
9000 (29500)
|
|
Diesel engine power, kW(hp)
|
224(300)
|
280(375)
|
403(540)
|
403(540)
|
470(630)
|
2x403(2x540)
|
2x470(2x630)
|
|
Drawworks rated power, kW(hp)
|
185(250)
|
260(350)
|
335(450)
|
410(550)
|
485(650)
|
560(750)
|
746(1000)
|
|
Main brake type
|
Band brake
|
Band or disc brake
|
Band or disc brake
|
Band or disc brake
|
Band or disc brake
|
Band brake or disc brake
|
Band brake or disc brake
|
|
Lines of travelling system
|
6
|
6
|
8
|
8
|
8
|
10
|
10
|
|
Drilling line dia., mm(in)
|
22（7/8）
|
26（1）
|
26（1）
|
29（1 1/8）
|
29（1 1/8）
|
32（1 1/4）
|
32（1 1/4）
|
|
Mast height, m(ft)
|
22（72）
|
32（105）
|
33（108）
|
33（108）
|
35（115）
|
38（125）
|
38（125）
|
|
Chassis
|
6x6
|
8x8 or 10x8
|
10x8
|
10x8
|
12x8
|
14x8
|
14x10
|
|
Min. ground clearance, mm
|
311
|
340
|
311
|
311
|
311
|
311
|
311
|
|
Max. climbing gradient
|
26%
|
30%
|
26%
|
26%
|
26%
|
26%
|
26%
|
|
Approach/departure angle
|
18°/12°
|
23°/16°
|
26°/17°
|
26°/18°
|
26°/18°
|
26°/18°
|
26°/18°
|
Packaging & Shipment
Packaging type: Export Seaworthy
Exporting port: Tianjin, Shanghai
