The MVI69-ADMNET Application Development Ethernet Communication Module
allows CompactLogix / MicroLogix processors to interface easily with Ethernet protocol
compatible devices and hosts.
The ADMNET solution is a powerful module designed with both Client and server
support. This broad support enables the module to function as a data collection
submaster, or to be a powerful slave as a remote off an HMI host. Applications for the
module are found in most industries, especially Manufacturing, Oil and Gas, Electrical
Power and Food Processing
|
Specification
|
|
Description
|
|
Dimensions
|
|
Standard 1769 single-slot module
|
|
|
|
|
|
Current Load
|
|
800 mA max @ 5 VDC
|
|
|
|
Power supply distance rating of 2 (L43 and L45
|
|
|
|
installations on first 2 slots of 1769 bus)
|
|
|
|
|
|
Operating Temp.
|
|
0°C to 60°C (32°F to 140°F)
|
|
|
|
|
|
Storage Temp.
|
|
-40°C to 85°C (-40°F to 185°F)
|
|
|
|
|
|
Relative Humidity
|
|
5% to 95% (with no condensation)
|
|
|
|
|
|
LED Indicators
|
|
Power and Module Status
|
|
|
|
Application Status
|
|
|
|
CFG Port Activity
|
|
|
|
Ethernet Port Activity
|
|
|
|
Error Status
|
Prosoft MVI69-ADMNET
Prosoft MVI69ADMNET
Email:sales3@amikon.cn
General Protocol Specifications
Allows software developers to access CompactLogix/MicroLogix processor and
Serial/Ethernet ports without needing detailed knowledge of the module’s hardware
design
API library functions are specified using the 'C' programming language syntax
The following compiler versions are compatible with the MVI69-ADMNET module
API:
o Digital Mars C++ 8.49 (included)
o Borland C++ V5.02
Operating System: General software DOS 6-XL
Flash ROM program space: 896 KB
RAM program and data space: 640 KB
More details please contact us !!!
|
MVI69-ADM
|
|
Programmable Application Development Module - 2 Serial Ports
|
|
|
|
|
|
MVI69-ADMNET
|
|
Programmable Application Development Module - 1 Ethernet & 2 Serial Ports
|
|
|
|
|
|
MVI69-MNET
|
|
Modbus TCP/IP Communication Module
|
|
|
|
|
|
MVI69-MNETC
|
|
Modbus TCP/IP Communication Module - Client Only
|
|
|
|
|
|
MVI69-HART
|
|
HART Multi-drop Communication Module - 4 Channel
|
|
|
|
|
|
MVI69-AFC
|
|
Gas & Oil Flow Computer (AGA-3, 7, 8, API 2540 & ISO 5167) 8 Meter Runs
|
|
|
|
|
|
MVI69-DFCM
|
|
DF1 Master/Slave Communication Module
|
|
|
|
|
|
MVI69-GSC
|
|
Generic ASCII Communication Module
|
|
|
|
|
|
MVI69-MCM
|
|
Modbus Master/Slave Communication Module
|
