Equipment size:9500（L）×2900（W）×1415（H）
B. Cleaning process:
Feeding→ high pressure spray washing→ detergent brush washing1→DI Spraying brush washing 1→DI Spraying brush washing 2→Pure water washing3→ 2 sets air knife drying→drying→remove static electricity →Discharge
C. Pass Line height:900 +/- 50mm
D. Washing speed:1~12m/min(adjustable)
Washing direction:The view of operation is from right to left
E.Glass cleaning method:Feeding: C/V、Discharge: C/V
F.Glass washing size:max width 1500mm,min 300*600mm (customized is accepted)
G.Electric cabinet:Set-top
