Ross Flex Testing Machine

Ross flex testing Machine is intended to determine the ability to withstand the cut growth of footwear sole subjected to repeated bending.

Test Standards

ASTM-D1052, SATRA TM60, ISO 5423, BS5131-2.1, GB/T 20265 ISO 20344-8.5, ISO 4643, etc.

Parameters

Model AT-F3008
Fixture 6 sets, can test 12pcs sample at the same time
Bending angle 90 °±2°
Bending speed (100±3)cpm for test standard of ASTM-D1052
（60±5）cpm for test standards of SATRA TM60, ISO 5423, BS5131-2.1, GB/T 20265 ISO 20344-8.5, ISO 4643, HG/T2411
Specimen dimension 150X25X5mm(ASTM-D1052) or 152X25X6.35mm (SATRA TM60, ISO 5423, BS5131-2.1, GB/T 20265 ISO 20344-8.5, ISO 4643, HG/T2411)
Counter 0~999,999
Dimension 610×500×550mm
Weight 90kg
Power 1phase, AC220V, 5A or specified
