Rotary lobe pumps for dairy application

Our pumps have a high position in the dairy industry. Our pumps are made of 316L and use a quick-fit interface to operate at low speeds to ensure food safety and integrity. Our pumps can be used. Stable conveying materials and easy to clean, our mechanical seals have been updated and replaced to achieve complete sealing and no oil leakage.Can be customized according to your needs.




Bonve offers the broadest range of its ROTARY LOBE PUMPS for dairy application. As a recognized market leader in pump technology, Bonve has been growing rapidly in the past 17 years since 2001. We make pumps to meet EHEDG, 3-A standards. Through the cumulative experience and technology, Bonve has supplied products satisfying customer by 100%.


Typical mediums to be transferred: butter, cheese, cream, egg, ice cream, milk, whey, yogurt.


ROTARY LOBE PUMPS for dairy application


How pump works?


ROTARY LOBE PUMPS for dairy application


The even rotation of the rotor pair creates a vacuum on the priming side of the pump, which can be defined by the direction of rotation of the drive. This vacuum draws the liquid into the pump chamber. With further rotation, the pumped medium is conveyed past the pump wall into the pressure area. Up to six chamber charges are displaced with each drive rotation– depending on the rotor type. When the rotor is at a standstill, the pump seals off almost completely.


Pump main structure


ROTARY LOBE PUMPS for dairy application

Pump Structure Features

ROTARY LOBE PUMPS for dairy application

ROTARY LOBE PUMPS for dairy application

ROTARY LOBE PUMPS for dairy application

ROTARY LOBE PUMPS for dairy application

ROTARY LOBE PUMPS for dairy applicationROTARY LOBE PUMPS for dairy applicationROTARY LOBE PUMPS for dairy applicationROTARY LOBE PUMPS for dairy application



What BONVE Lobe Pump advantages?


Sanitary construction

All liquid metal contacting parts are made of stainless steel 316, corrosion resistance.

Cost effective,  easy maintenance

High efficiency and energy-saving, stable transmission, low failure rate, good sealing and low noise.

High volumetric efficiency

Up to 85%

Low shear pumping

Minimal damage to extremely shear sensitive cultured media, such as yogurt.

CIPSIP ability

Temperatures up to 200ºC



Who used our pumps?


ROTARY LOBE PUMPS for dairy application


How to choose our pump?


Selection Guideline

                                            Liquid name:__________

Viscosity:                cp          Density:                        Temperature:             ℃        PH value:

Solid content:                         Max. size of particle:

Capacity: Max. required              LH                 Working required__________ LH

Discharge pressure: Max. required__________Mpa                Working required__________ Mpa

Connection type required: Thread[          ]       Clamp[          ]

Installation type: Fixed [          ]        Movable[         ]

Voltage:              V        Frequency:             Hz

Liquid contact material: SS304[          ]      316[          ] 316L[          ]

Special request_____________________________________

                  Order qty.


Thanks for your interest into our rotary lobe pump, hope we can solve your pumping problem during your dairy application. Contact our sales engineer - Mr. Andre Chen for a pump solution.
