SFP Copper RJ45 Module 10/100/1000 Mbps Modules Ethernet to SFP

SFP Copper RJ45 Module is high performance, cost-effective module compliant with the Gigabit Ethernet and 1000- BASE-T standards as specified in IEEE 802. 3-2002 and IEEE 802.3ab, which supporting 1000Mbps data- rate up to 100 meters reach over unshielded twisted-pair CAT 5 cable. The module supports1000 Mbps (or 10/100/1000Mbps Modules) full duplex data-links with 5-level Pulse Amplitude Modulation (PAM) signals. All four pairs in the cable are used with symbol rate at 250Mbps on each pair.Ethernet to SFP,The module provides standard serial ID information compliant with SFP MSA, which can be accessed with an address of A0h via the 2wire serial CMOS EEPROM protocol. The physical IC can also be accessed via 2wire serial bus at address ACh.

• WavelengthN/A
• Distance100 M
• Data Rate1000/100/10 M
• ConditionCompatible
• Temperature0°C to 85°C
• Warranty3 Years
• ConnectorRJ45

---
