405-15ABM |high-performance analog input module
Sales Manager: May | Email: ab@mooreplc.com | Phone: +8618106909650 (WhatsApp) | WeChat: dcsfcs
Industrial Power Supply Module | Global 3-day DHL | 12-month warranty
What it is
The 405-15ABM is a high-performance analog input module designed for industrial automation systems.
It supports a variety of analog signal inputs, including current and voltage signals.
Key features include:
l Flowmeter Interface: Connects to various flowmeters, accepting pulse, frequency, or 4-20 mA analog inputs.
l Process Control: Used in automated control systems for the chemical, petroleum, and pharmaceutical industries.
l Data Acquisition: Collects analog signals in real time for processing by a host computer or control system.
Technical Specifications
Input Type: 4-20 mA, 0-20 mA, 1-5 V, 0-10 V
Input Impedance: Current: 250 Ω; Voltage: 10 kΩ
Accuracy: ±0.075%
Zero Adjustment: 0.00000 to 50,000
Span Adjustment: 0.1000 to 50,000
Stop Point Setting: Programmable low flow cutoff
Relationship Type: Linear, square root, or programmable
Power Supply: 8-24 V DC, 50 mA maximum
Operating Temperature Range: 0 to 55°C
Typical Applications and System Integration
Multiple Input Support: Compatible with a variety of analog signal inputs to meet diverse application needs.
High-Precision Measurement: Provides high accuracy of ±0.075%, ensuring data accuracy.
Flexible Configuration: Supports zero and span adjustment to adapt to varying operating conditions.
Rugged and Durable: IP65 protection rating, suitable for harsh industrial environments.
