Single layer black ceramic non-stick coating C-105

C-105 is single layer ceramic coating, smooth hand feeling, excellent heat resistance, excellent non-stick performance and abrasion resistant It can be used on non-stick cookware and household appliance.



Description

Single layer black ceramic non-stick coating C-105 is single layer ceramic coating, smooth hand feeling, excellent heat resistance, excellent non-stick performance and abrasion resistant It can be used on non-stick cookware and household appliance.


Type

Ceramic nano material


Key features

-PFOA free

-Excellent heat resistant (>400℃)

-Excellent non-stick performance and easy to clean

-Superior chemical resistance and abrasive resistance


Typical properties

Appearance: Black

Solid content (%): 52±1

Viscosity (cp): 600~1000

Density (g/ml): 1.20

Color of the film surface: Black

Curing temperature (℃): 280-300

Gloss (60° glossimeter): >35

Film thickness (μm): 30-45

Non-stick performance: >10 cycles (Fry eggs at 170±10℃)

Corrosion resistance: No blister (Boling 10% salt water for 24 hours)

Abrasion resistance 3KG/21cm2: >8000 cycles

Hardness (ZHONGHUA pencil): >6H


Application

-Aluminum and stainless steel fry pan, wok, soup pot, rice cooker, electric pressure cooker, electric saucepan, electric baking tray, cake mould etc.


Storage and Handling

Available in 20 kg/ barrel or 30 kg/ barrel

Store products in tightly closed original containers at 5-40℃

Shelf life: 9 months from delivery date

According to non-dangerous goods transport


Non-stick Coating Type

↓ ↓ ↓ Please click product model for more informations

Model Layer Thickness Curing temperature Non stick property Anti-corrosion Abrasion resistant
  Water based fluororesin non-stick coating
PF-600 2 25-40 380-400 A A A A A A A A A A A A
PF-601 2 25-35 380-400 A A A A A A A A A A A
PF-602 2 25-40 380-400 A A A A A A A A A A A A
PF-610 3 20-35 380-420 A A A A A A A A A A A A A
PF-611 3 20-35 380-420 A A A A A A A A A A A A A
PF-612 3 20-35 380-420 A A A A A A A A A A A A A
  Water based ceramic non-stick coating
C-104 1 30-45 280-300 A A A A A A A A A A A A A A
C-105 1 30-45 280-300 A A A A A A A A A A A A A A
C-106 2 34-50 280-300 A A A A A A A A A A A A A A
C-107 1 12-20 250-280 A A A A A A A A A A A A A A
C-108 2 34-50 280-300 A A A A A A A A A A A A A A
C-109 2 34-50 280-300 A A A A A A A A A A A A A A
  Silicone resin non-stick coating
S-200 1 15-20 280-300 A A A A A A A A A A A A A
S-201 1 15-20 280-300 A A A A A A A A A A A A A A
S-202 1 15-20 280-300 A A A A A A A A A A A A A
