advanced core patented technology
|
|
high safety, triple anti-pinch
|
|
high stability, optimize the mechanism structure
|
|
long life, longer than 10 million times
|
|
|
|
|
|
|
|
|
|
accurate & fast detection
|
|
high visitor flow rate usage
|
|
modular design, easy maintenance
|
|
high compatibility, high integration
|
Advanced & Intelligent Turnstile Core Technology
Long service life
The mechanism and control system of intelligent flap barrier turnstile have been passed 10 million times life test.
Advanced core logic algorithm
The flap barrier turnstile adopts CMOLO® patented passing detection algorithm and matrix photoelectric stereo detection technology, to sensitively detect illegal behaviors such as reversely passing and tailgating, and issues warnings in the form of sound and light, and can be linked with other security systems.
The smart flap barrier turnstile adopts advanced servo control system and DSP+ARM motor control technology, combined with the motor control algorithm independently developed by CMOLO, which can achieve precise control and positioning of the obstacle and maintain stable performance.
Strong & stable mechanism structure
CMOLO's self-developed lossless modular mechanism structure and full CNC processing technology are to ensure that the precision and strength of the mechanism, and the use of advanced connecting arm design, so as to ensure the stability and long service life of the mechanism structure.
All-around Pedestrian Safety Protection
Emergency open
The smart flap barrier turnstile equips with emergency escape control device, to make the system automatically open the flap to evacuate pedestrian.
Turnstile opens when power failure
With advanced and reliable design of automatic opening after power failure, the flap barrier turnstile system will automatically unlock to make the passageway be an open status, which will be easier to evacuate pedestrian in the event of an emergency.
Anti-electric shock
All electric modules are designed to operate under the safety voltage of 24V, and configured with residual current protective device to prevent pedestrian from being injured by electric shocks.
Triple anti-clamping
With triple anti-clamping technologies such as infrared anti-clamping, mechanical anti-clamping and anti-collision by advanced electric current detection, the intelligent flap barrier turnstile can protect pedestrian safety more comprehensively.
Customization
| Appearance |
Cabinet size, material and surface treatment process etc. of turnstile can be moderately customized. |
Material of the gate
|
Tempered glass / acrylic / polycarbonate, and color can be customized. |
Function
|
Built-in or external counter
TCP / IP communication function
Audible and visual alarm function
|
| System integration |
The installation position of direction indicator can be adjusted.
The shape of direction indicator can be customized.
|
| Direction Indicator |
Integrate with access control system, human body temperature measurement system, ticketing system, time attendance system, visitor system etc.
Integrate with QR code, face, fingerprint, ID/IC card, passport identification system etc.
Integrate with card collection system, and customize card collection device
|
