SMC CDM2E32-100Z CM2/CDM2-Z Series Aluminum Alloy Mini Cylinder

Core Features

• ✓  Double-acting pneumatic drive: Compressed air drives the piston in both directions, achieving push-pull function.
• ✓  Built-in magnetic ring: Can be used with an external magnetic switch for piston position detection and automated control.
• ✓  Standard rod end internal thread: The rod end uses a standardized internal thread for easy direct connection to the load.
• ✓  Compact and lightweight design: Aluminum alloy construction combined with a stainless steel cylinder results in a compact structure suitable for use in confined spaces.

Q: What kind of equipment is the CDM2E32-100Z suitable for?

A: This cylinder is suitable for installation in space-constrained equipment requiring a swing connection and a long stroke, such as automated assembly machinery, light-duty handling equipment, small packaging machinery, and semiconductor manufacturing equipment. Its integrated earring mounting design is particularly suitable for applications requiring swinging motion. Due to its long stroke (100mm), it is suitable for applications requiring medium push-pull distances.

Q: Can this cylinder be used with a magnetic switch?

A: Yes. The CDM2E32-100Z has a built-in magnetic ring and can be paired with small magnetic switches such as the SMC D-M9 series for piston position detection. These magnetic switches offer convenient position adjustment, support fine adjustment, and have a transparent switch bracket for easy observation of the switch status.

Q: What are the characteristics of the "integrated earring basic type" mounting configuration of the CDM2E32-100Z? How to select mounting accessories?

A: The "E" in the model number indicates that the installation type is "earring integrated basic type," meaning the cylinder body has an earring-type mounting structure that can be directly connected to the swing base. The SMC CM2-Z series has swing bases specifically designed for single earring and trunnion types, and offers models with integrated mounting parts, eliminating the need to order the cylinder and mounting parts separately, saving the trouble of ordering them separately.
