SMC CDM2E32-50Z CM2/CDM2-Z Series Aluminum Alloy Mini Cylinder

Core Features

• ✓  Double-acting pneumatic drive: Compressed air drives the piston in both directions, achieving push-pull function.
• ✓  Built-in magnetic ring: Can be used with an external magnetic switch for piston position detection and automated control.
• ✓  Standard rod end internal thread: The rod end uses a standardized internal thread for easy direct connection to the load.
• ✓  Compact and lightweight design: Aluminum alloy construction combined with a stainless steel cylinder results in a compact structure suitable for use in confined spaces.

Q: What kind of equipment is the CDM2E32-50Z suitable for?

A: This cylinder is suitable for installation in compact equipment requiring a swing connection, such as automated assembly machinery, light-duty handling equipment, small packaging machinery, and semiconductor manufacturing equipment. Its integrated earring mounting design is particularly suitable for applications requiring the cylinder to perform swinging motions.

Q: Can this cylinder be used with a magnetic switch?

A: Yes. The CDM2E32-50Z has a built-in magnetic ring and can be paired with small magnetic switches such as the SMC D-M9 series for piston position detection. This series of magnetic switches offers convenient position adjustment and supports fine adjustment..

Q: What are the characteristics of the "integrated earring basic type" mounting configuration of the CDM2E32-50Z? How do I select a swing base?

A: The "E" in the model number indicates that the mounting configuration is "integrated earring basic type," meaning the cylinder body has a built-in earring mounting structure and can be directly connected to a swing base. The SMC CM2-Z series features a swing base specifically designed for single-ear loop and trunnion types, and a model with integrated mounting hardware is available, eliminating the need to order cylinders and mounting hardware separately, allowing for a one-stop solution.
