Q: When is VBA20A-F03GN needed?
A: When the factory's standard air source pressure (e.g., 0.5MPa) is insufficient to drive certain equipment (such as large-bore cylinders or pneumatic presses), it can easily boost the local pressure to 1.0MPa without replacing the air compressor.
Q: Can it be used in cleanrooms or the food industry?
A: This model is the standard specification. For applications with special cleanliness or corrosion resistance requirements, it is recommended to select a variant with appropriate protection (e.g., rust prevention).
Q: Are there any special installation requirements?
A: The booster valve must be installed horizontally (piston in a horizontal position) to ensure the proper functioning of its internal reversing valve. It is also recommended to install an air filter on its secondary side (outlet side) to prevent trace dust generated by internal sliding parts from affecting downstream applications.
