Solar PV Module Ground Mount Racking

Solar PV Module Ground Mount Racking Systems with high preassembly ,strength structure and various design and easy to install ,solar panel mounting brackets will be the best chooice for the ground mounted solar panels.


  • Warranty10years, 25years service life
  • PaymentT/T , Paypal,Escrow,West Union
  • Lead time10 workdays
  • CertificateGB50009,JIS C8955,DIN 1055
  • Wind Load45m/s
  • SlopeCustomized
  • MaterialAluminium alloy
  • TypeGround

Solar Pv Ground Mounting Racking Systems.

pole mounted solar panels

GROUND SOLAR PANEL BRACKET

solar pole mount solar panel rack

GROUND SOLAR BRACKET SPECIFICATIONS

▶ Installation site                               Flat roof.

▶ Installation angle                           5°,10°

▶Wind speed                                        <45m/s.

▶Snow load                                           <1.2KN/m2.

▶Build height                                       <20m.

▶Material                                                 AI 6063-T5 & SUS304.

▶Surface treatment                         HDG.

▶Refer to standard                         GB50009,JIS C8955,DIN 1055

▶Warranty                                             15-year warranty , 25-year service life.


GROUND SOLAR RACKING SYSTEM HARDWARES

solar panel pole mount

▶  Ground Pole Mount Solar Racking with Q235B steel bracket as main body material,HDG surface treatment, service life is more than 25 years.

▶  Cement based implanted in the ground makes the connection is frim,embedded bolt will be set into cement based to convenient installation between Mounting Pole Foot and cement based.

▶  Ground Mounting Brackets for Solar Panels with features :convenient installation, low cost ,suitable for large-scale Photovoltaic Power Station Constructure.

▶  Concrete foundation Solar Panel Rail Mount suits for all kinds of soil. We optimized the wind and snow load resistance performance, and can bear larger span and larger pressure, realize the optimal design proposal.


PACKING

solar panel fasteners


TO HELP YOU GET THE RIGHT SYSTEM,PLEASE KINDLY OFFER THE FOLLOWING NECESSARY INFO:

1. Dimension of solar panels(length*width*thickness)?

2. Quantity of solar panels?

3. Where to install : rooftop (flat roof or pitched roof ) or ground ?

4. Tilt angle?

5. Any requirements about wind load and snow load?

6. Any minimum height requirement(distance from ground to panel)?
