| Input DC (PV side) |
| Recommended max. PV array size |
150 kW |
160 kW |
200 kW |
200 kW |
250 kW |
| Max.usable PV input power |
150 kW |
160 kW |
200 kW |
200 kW |
250 kW |
| Max.input voltage |
1000 V |
| Rated voltage |
600 V |
| Start-up voltage |
180 V |
| MPPT voltage range |
150-950V |
| Max. input current |
10×42A |
| Max. short circuit current |
10×60A |
| MPPT number / Max. input strings number |
10/20 |
| Battery |
| Battery type |
Li-ion |
| Battery voltage range |
300 - 950 V |
| Max. charge / discharge current |
200 A / 100 A + 100 A |
| Number of battery ports |
2 |
| Max. charge / discharge current of each port |
100 A |
| Communication |
CAN / RS485 |
| Output AC(Grid side) |
| Rated output power |
75kW |
80 kW |
99.9kW |
100 kW |
125kW |
| Max.apparent output power |
75KVA |
80 KVA |
99.9 KVA |
100 kVA |
125kVA |
| Rated grid voltage |
3/N/PE,220V/380V,230V/400V |
| Rated grid frequency |
50 Hz/60Hz |
| Rated grid output current |
114 A / 108.3 A |
121.6 A / 115.5 A |
151.8 A / 144.2 A |
151.9 A / 144.3 A |
189.9 A / 180.4 A |
| Power factor |
> 0.99 (0.8 leading - 0.8 lagging) |
| THDi |
< 3% |
| InputAC(Grid side) |
| Max. input current |
250 A |
| Output AC (Back-up) |
| Rated output power |
75kW |
80 kW |
99.9kW |
100 kW |
125kW |
| Max. apparent output power |
75-100K: 1.2 times of rated power, 10 mins; 1.4 times of rated power, 100 s; 1.6 times of rated power, 10 s; 2 times of rated power,
200 ms; 125K: 1.2 times of rated power, 100 s; 1.4 times of rated power, 10 s; 1.6 times of rated power, 200 ms |
| Back-up switch time |
>10 ms |
| Rated output voltage |
3/N/PE, 220 V / 380 V, 230 V / 400 V |
| Rated frequency |
50HZ/60HZ |
| THDv(@linear load) |
>2% |
| Input AC (Generator) |
| Max. input power |
75kW |
80 kW |
99.9kW |
100KW |
125 kW |
| Rated input current |
114.0A/108.3A |
121.6A/115.5A |
151.8A/144.2A |
151.9A/144.3A |
189.9A/180.4A |
| Rated input voltage |
3/N/PE,220V/380V;3/N/PE,230V/400V |
| Rated input frequency |
50Hz/60 Hz |
| Efficiency |
| Max. efficiency |
97.6% |
| EU efficiency |
97.29% |
| BAT charged / discharged to AC max. efficiency |
97.0% |
| Protection |
| Anti-islanding protection |
Yes |
| Output over current protection |
Yes |
| Short circuit protection |
Yes |
| Integrated DC switch |
Yes |
| DC reverse-polarity protection |
Yes |
| Surge protection |
DC Type ll/AC Type ll |
| Integrated AFCI 2.0 |
Yes |
Optional |
Optional (Brazil: Yes) |
| Protection class / Over voltage category |
I/ DC II, AC III |
| General Data |
| Max allowable phase imbalance (grid & back-up) |
100% |
| Max.power per phase (grid&back-up) |
25.00 kW |
26.66 kW |
33.3 kW |
33.3 kW |
41.66 kW |
| Dimensions(W×H×D) |
1174 × 814 × 400 mm |
| Weight |
170 kg |
| Topology |
Transformerless |
| Operating ambient temperature range |
-25~+60°℃ |
| Relative humidity |
0-100% |
| Ingress protection |
IP66 |
| Cooling concept |
Intelligent fan-cooling |
| Max.operation altitude |
3000m |
| Grid connection standard |
G99, VDE-AR-N 4105/VDE V 0124, EN 50549-1&2/EN 50549-10, VDE 0126/UTE C 15/VFR:2019, NTS 631/RD 1699/RD 244/
UNE 206006/UNE 206007-1, CEI 0-21, C10/11, NRS 097-2-1, TOR, EIFS 2018.2, IEC 62116, IEC 61727, IEC 60068, IEC 61683,
EN 50530, MEA, PEA,PORTARIA Nº 140, DE 21 DE MARÇO DE 2022;
Brazil (75K: ORDINANCE (PORTARIA) NO.140, ORDINANCE NO. 515; 100K/125K: NBR 16149, NBR 16150, IEC 62116) |
| Safety/EMCstandard |
IEC/EN 62109-1/-2,IEC/EN61000-6-2/-4,EN55011 |
| Features |
| PVconnection |
MC4 Quick connection plug |
| Battery connection |
Terminal connector |
| AC connection |
Terminal block |
| Display |
7.0" LCD display & Bluetooth + APP |
| Communication |
CAN, RS485-115200, Ethernet, Optional: Wi-Fi, Cellular, LAN |
