TC32 3inch RS232/TTL thermal embedded panel printer with auto cutter

Technical parameters

Item	TC32(3inch) 60mm Paper Roll
Printing method	Thermal printing
Resolution	203DPI, 8 dots/mm
Paper width	79.5±0.5mm
Printing width	72mm
Interfaces	USB+RS232/TTL+ Drawer
Paper cutting	Manual or Automatic cutting
Command set	ESC/POS compatible commands
Print Font	ASCII Font A: 12×24/ASCII Font B: 9×24/Chinese: 24×24
Graphics printing	Support dots printing with different densities, raster bitmap print and downloaded bit image print
Code pages	Support Chinese, English, Japanese and other 45 kinds of international character sets
UTF-8	Support
Bar codes	UPC-A; UPC-E; EAN-8; EAN13; CODE39; ITF; CODEBAR; CODE128; CODE93; QR CODE
External dimension	137.5mm×116mm×73.6mm
Opening dimension	130mm×108mm(L×W)
Paper roll diameter	60mm(Max)
TPH life	100km
Cutter life	1,000,000 times
Power Supply	24V
