EPA Tier 4 Volvo Penta Electric Generator Suppliers TAD1342GE 280kw 350kva Prime Power Of Generator
The TAD1342GE is a powerful, reliable and economical Generating Set Diesel Engine built on the dependable Volvo inline six concept. Durability & low noise Designed for easy, fast and economical installation. Field tested to ensure highest standard of durability and long life. Well-balanced to produce smooth and vibration-free op er a tion with low noise level. To maintain a controlled working temper a ture in cylinders and combustion cham bers, the engine is equipped with piston cooling. The engine is also fi tted with replaceable cylinder liners and valve seats/guides to ensure maximum du ra bili ty and service life of the engine.
Low exhaust & noise emission The state of the art, high-tech injection and highly effi cient charge air system with low internal loss es contributes to excellent com bus tion and low fuel consumption. The TAD1342GE is EU Stage 2 emission certifi ed. An electronically controlled viscous fan drive is available giving substantially lower noise and fuel consumption.
Exhaust emissions
The engine complies with EU stage 2 emission legislation according to the Non Road Directive EU 97/68/EEC. The engine also complies with TA-luft -50% exhaust emission regulations.
TWD1645GE is a reliable, powerful and compact in-line 6 cylinder diesel engine. It´s designed to power a wide range of stand-by and prime power generator sets.This 16 liter diesel engine utilizes dual-stage turbochargers and heavy-duty steel pistons to provide excellent power
density.It features a proven combustion technology with highpressure unit injectors, resulting in high fuel efficiency and low exhaust emission levels.
The engine also features a compact and low weight design that is well-balanced, providing smooth operation with low noise and vibration. It´s designed for easily accessible service points. A wide range of options is available, including a heavy-duty frame, cooling package and air-filter that will suit a variety of installations.
|
Diesel generator Details
|
|
Model
|
AI-350GF
|
|
Power
|
350kw/437.5kva
|
|
Frequency
|
50Hz/60Hz
|
|
Voltage
|
380/220v(voltage can be customized)
|
|
Optional Type
|
Open/soundproof/trailer
|
|
Size of Open type
|
3100*1150*1600mm
|
|
Weight of Open type
|
3050kg
|
|
|
|
With Diesel Engine
|
|
Brand&model
|
With genuine Volvo engine TAD1344GE
|
|
Standby Power
|
389kw
|
|
Cylinders
|
6 in line arrangement
|
|
Bore*Stroke
|
131*158mm
|
|
Displacement
|
12.78L
|
|
Lubrication Oil Capacity
|
35L
|
|
Fuel Consumption at 100% Load
|
199g/kw.h
|
|
Speed Governor
|
ECU
|
|
|
|
With Alternator
|
|
Optional Brands
|
Stamford/Leroy Somer/Mecc Alte/Marathon
|
|
Exciter type
|
Single bearing,brushless,Self-excited
|
|
Power factor
|
0.8
|
|
Voltage adjust range
|
≥5%
|
|
Insulation Grade
|
H
|
|
Protection Grade
|
IP23
|
|
|
|
With Controller
|
|
Optional brands
|
Deepsea/ComAp/Smartgen
|
Power standards The engine performance corresponds to ISO 3046, BS 5514 and DIN 6271. The technical data applies to an engine without cooling fan and operating on a fuel with calorific value of 42.7 MJ / kg (18360 BTU/lb) and a density of 0.84 kg/liter (7.01 lb/US gal), also where this involves a deviation from the standards. Power output guaranteed within 0 to +2% att rated ambient conditions at delivery. Ratings are based on ISO 8528. Engine speed governing in accordance with ISO 8528-5.
