1.Why “Supervised”
The 3625 is the only Triconex DO card that keeps beating while it sleeps: every 50 ms in the OFF state it injects a 2 mA diagnostic pulse.
Broken wires, missing loads or shorts-to-supply are reported in <100 ms—long before the safety function is called—giving every conductor its own built-in continuity tester.
2.Two densities, one slot
3625-16: 16 ch, steel-blue label, 0.8 A/pt—perfect for high-impedance pilot valves
3625-32: 32 ch, dark-blue label, 1.7 A/pt—double the density, only 30 % more power
Both use triple-modular-redundant MOSFET voters; lose two legs and the 2oo3 verdict still holds.
3.Key specs at a glance (factory sheet rev. 2025-04)
|
Item
|
3625-16
|
3625-32
|
|
Part No.
|
3625-16
|
3625
|
|
Channels
|
16 common-neg
|
32 common-neg
|
|
Voltage
|
16-32 VDC
|
16-32 VDC
|
|
Steady current
|
0.8 A/pt
|
1.7 A/pt
|
|
Surge
|
4 A/10 ms
|
7 A/10 ms
|
|
Min. load
|
30 mA
|
10 mA
|
|
OFF pulse
|
2 mA, 200 µs
|
2 mA, 200 µs
|
|
Wire-break
|
<100 ms
|
<100 ms
|
|
Isolation
|
1 500 VDC
|
1 500 VDC
|
|
MTBF
|
312 yrs
|
285 yrs
|
|
Temp
|
-40…+70 °C
|
-40…+70 °C
|
|
Cert
|
SIL 3 / ATEX Zone 2
|
SIL 3 / ATEX Zone 2
|
