1. Product snapshot
The 4000103-510 is the factory-made Extension-Termination-Assembly (ETA) cable that links any TRICONEX main rack to its first (or second) expansion chassis.
30-conductor, fully shielded, impedance-matched and UL-listed for SIL-3 safety loops. One end: 37-pin D-sub male; opposite end: 37-pin D-sub female; thumbscrews on both sides.
31-Length exactly 3 m (9.84 ft) – the only length certified by Schneider for fault-tolerant communication up to 1 MHz.
2. Mechanical & electrical data
|
Parameter
|
Value / note
|
|
Part number
|
4000103-510 (also printed on cable tag)
|
|
Length
|
3 m ± 0.05 m
|
|
Connector style
|
37-pin D-sub, male / female, #4-40 screw
|
|
Wire gauge
|
24 AWG stranded, tinned copper
|
|
Shielding
|
100 % foil + 85 % braid, 360° shell
|
|
Voltage rating
|
300 V rms
|
|
Temperature range (operation)
|
–20 … +70 °C
|
|
Bending radius
|
≥ 5 × OD (OD = 11 mm)
|
|
Flame class
|
VW-1, UL 758
|
|
Compatibility
|
Tricon v9, v10, Trident, MP3008 racks
|
3. Drop-in replacement checklist
✓ Same keying slots – no re-pinning needed
✓ Identical ferrite bead placement for EMC
✓ Factory pull-test certificate included (ISO 13849-1)
4. Shipping & service snapshot
|
Stock status
|
Lead-time
|
Packaging
|
Warranty
|
Global courier
|
|
In stock – large qty
|
24 h dispatch
|
Anti-static bag + foam box
|
12 months
|
DHL/FedEx/TNT/UPS
|
Service keywords: Brand-new original, best price, 24/7 quote, integrity supply, fast delivery.
What happens next?
-
-
-
Your quote
You’ll get a fully customized quote to fit your unique needs.
-
