1.Product snapshot
|
Model
|
9662-110 Analog Input Terminal Board
|
|
Architecture
|
Triple-redundant (TMR)
|
|
Safety level
|
SIL 3 / IEC 61508, ATEX & FM option
|
|
Input range
|
0-10 V, ±10 V, 0-20 mA, 4-20 mA (jumper-free)
|
|
Accuracy
|
±0.1 % of span
|
|
Resolution
|
16 bit
|
|
Channels
|
16 AI + 4 cold-junction (if RTD/TC)
|
|
Scan rate
|
5 ms per channel, max 1 kHz aggregate
|
|
Isolation
|
250 V channel-to-bus, 1500 V field-to-ground
|
|
Power
|
24 VDC from Tricon rail, < 30 W
|
|
Temp
|
–40 °C to +85 °C (operational)
|
|
Protection
|
IP 66 front, over-voltage & short-circuit proof
|
|
Size / weight
|
19" rack 4 TE, ≈ 2.3 kg
|
2.Compatibility and Usage
The 9662-110 panel is compatible with 115 VDC digital input modules, such as the Triconex 3613E module, which provides 8 input points.
Each termination panel supports 8 points, so one panel is required per module. The panel includes labels to facilitate proper wiring and identification.
3.Features and Benefits
ü · Fuse Protection: Each input point is equipped with a fuse and a blown-fuse indicator, enhancing system reliability and safety.
ü · Non-commoned Power Terminals: Simplifies wiring by using separate power connections for each input point.
ü · Flexible Mounting Options: Can be mounted on a DIN rail, offering versatility in installation.
ü · Wide Operating Temperature Range: Suitable for diverse industrial environments, operating between -40°C and +70°C.
