Indicators
|
|
Maximum tracking distance
(Under favorable weather conditions, for a 0.35 × 0.35m drone)
|
thermal imaging
|
visible light
|
|
>2km
|
>3km
|
|
Tracking mode
|
Manual, automatic, radar/spectrum linkage
|
|
Servo performance
|
Maximum speed in azimuth: ≥ 90 °/s, maximum pitch speed: ≥ 90°/s；
Maximum acceleration in azimuth and elevation: ≥ 100°/s2
|
|
Power Supply
|
AC220V，50Hz
|
|
Size
|
575mm×475mm×655mm
|
|
Weight
|
≤80kg
|
|
Surveillance scope
|
Direction 0-360 °; Pitch -45 °~+90 °
|
|
working temperature
|
-40℃～+60℃，90%±3%
|
|
Infrared thermal imaging
|
|
detector
|
Uncooled focal plane VOx detector
|
|
pixel
|
1280×1024
|
|
Sensitivity (NETD)
|
Better than 50mk
|
|
Working band
|
8-14um long wave infrared
|
|
focal length
|
30-300mm, continuously variable magnification
|
|
focusing
|
Manual, automatic
|
|
image enhancement
|
SDE digital detail enhancement function
|
|
Electronic amplification
|
2X, 4X
|
|
correcting
|
Automatic, manual, background correction
|
|
Image module
|
Hot white, hot black
|
|
Parameter adjustment
|
Brightness, contrast, AGC automatic control
|
|
Start time
|
≤20s
|
|
High definition visible light
|
|
detector
|
CCD， Target surface 1/1.8 ", color to black
|
|
resolving power
|
1920 × 1080.2 million
|
|
Interface and video format
|
H. 264 video compression, IP network output
|
|
illumination
|
Minimum 0.002lux
|
|
focal length
|
22.2mm~755mm, infrared corrected electric continuous zoom lens, automatic focusing
|
|
Field of view angle
|
18.12°×13.48°～0.54°×0.41°
|
|
lens control
|
Electric zoom, manual/automatic focusing, automatic aperture
|
|
Enhanced fog penetration
|
Optical and electronic dual fog transmission
|
|
Servo turntable
|
|
Rotation speed
|
Horizontal 0.01 °~90 °/S; Pitch 0.01 °~90 °/S (continuously variable speed)
|
|
acceleration
|
Horizontal 100 °/S2; Pitch 100 °/S2
|
|
Rotation angle
|
Horizontal range of 0-360 °; Pitch -45 °~+90 °
|
|
Preset position
|
200
|
|
Cruise scanning function
|
Equipped with multi-point preset cruise control and adjustable cruise speed
|
|
Bearing method
|
Shelf load
|
|
Transmission mode
|
Servo motor direct drive
|
|
positioning accuracy
|
0.02°
|
|
Embedded automatic tracking module
|
|
Video interface
|
Support visible/infrared video switching and tracking
|
|
Video format
|
Composite video, 1Vp-p, 625/525 lines, CCIR，PAL，NTSC
|
|
communication interface
|
1 RS232 configuration interface, 1 RS232 motor drive interface
|
|
object detection
|
Capable of detecting multiple and single targets
|
|
Tracking function
|
Built in multiple tracking algorithms and supporting multi-target detection and tracking;
|
|
Locking and Recapture Algorithm for Transient Loss of Intelligent Targets
|
|
control interface
|
|
network interface
|
Be connected to the local LAN through RJ45 Ethernet port to share high-definition video on the network
|
|
interface protocol
|
Pelco-D, P protocol, 2400/4800/9600/19200bps,
|
|
Support ONVIF protocol
|
|
Interface style
|
Aviation waterproof plug
|
|
Environmental Indicators
|
|
working temperature
|
-40℃～+60℃
|
|
Storage temperature
|
-45℃～+65℃
|
|
Humidity
|
<90%
|
|
anti-seismic
|
0.2g（GB/T15211—2013.5.4）
|
|
Impact resistance
|
15g（GB/T15211—2013.5.3）
|
|
Lightning surge protection
|
Power supply 4000V, communication video signal 2000V
|
|
Salt spray prevention
|
When the PH value is 6.5~7.2, the surface does not change after 48 hours of continuous spray
|
|
Protection level
|
IP66
|
|
The above parameters are for reference only. Detailed product parameters are subject to actual delivery.
|
