UN 4*4 wheel drive military truck
Best supplier for china UN 4*4 wheel drive military truck 290 hp engine, with Germnay mercedes benz technology, 11.00-20 tyre. China north benz truck chassis authorized manufacturer for beiben 4*4 drive cargo truck, beiben 4*4 drive truck mounted crane.
The series products of our UN 4*4 wheel drive military truck are ideal
transport with outstanding performance and high quality, they are widely used
in industries and sectors, such as national defense, aviation, postal service,
railways, highways, harbors, petroleum, chemicals, water and electricity,
forests, fire fighting, banks and peace keeping forces.
benz 4*4 military truck in producing line for using in UN
|
Vehicle Name:
|
Beiben 4*4 truck chassis
|
|
Types of drive
|
Left hand drive (LHD
)
|
|
Truck model number
|
1626S
|
|
Dimension (mm)
|
8665*2495*3145
|
|
Curb weight (kgs)
|
7440
|
|
Drive wheel
|
4×4
|
|
Engine model
|
WD10.300 Diesel 4-stroke
direct injection engine, 6-cylinder in-line with water cooling,
turbo-charging & intercooling
|
|
Horsepower(hp)
|
300
|
|
Bore*stroke (MM)
|
126*155
|
|
Displacement (L)
|
9.726
|
|
Rated speed (R/min)
|
2200
|
|
Max torque (Nm)
|
1160
|
|
Max Torque speed( R/min)
|
1200-1600
|
|
Lowest fuel consumption (G/kw.h)
|
< 198
|
|
Net weight (KG)
|
870
|
|
Meridian tire
|
12.00-20
|
|
Number of tires
|
6 + 1(spare wheel)
|
|
Saddle types
|
None
|
|
Transmission types :
|
RT11509C
|
|
Steering mechanism:
|
TAS85
|
|
Wheelbase (mm)
|
4800
|
|
Cab style
|
Long cabin, Benz technology ,without
bed
|
|
Air-condition
|
With air-condition
|
|
Cab body style
|
The whole steel ,The driver’s seat adjustable
, high safety,lower wind resistance coefficient, Benz Technology.
|
|
Steering system
|
High safe and reliable, and flexible, ZF8098
|
|
Brake system
|
Service brake ,Can automatically adjust the
brake clearance, Double air brake system , WEVB
|
|
Electric system:
|
Stronger load ability, high reliability and
easy maintenance
|
|
Truck frame style
|
Fish maw shape, inequilaterally section, equal
intensity, Benz technology
|
|
Front axle
|
Benz 7.0T Transaxle
|
|
Rear axle
|
Benz
Technology,double deceleration bridge, high
efficiency, carrying large, Mercedes
Benz strengthened axle (punching-welding axle housing, double
reduction driving axle, inter-wheel differential and differential lock)
Ratio=5.263
|
|
Electric system:
|
Stronger load ability, high reliability and
easy maintenance,24 V
|
|
Emission standard
|
Eur 2 & EURO 3
|
|
Fuel tank capacity (L)
|
400
|
|
Optional equipment
|
Saddle , upper berth, ABS , squareness
silencer.
|
