GSI124 in One Minute
1. Output: 4-20 mA loop + raw accel. via BNC
2. Supply: 18-30 V DC with reverse-polarity guard
3. Range: 0-25 mm/s RMS (default), jumper-select 0-10 / 0-50 mm/s
4. Freq. resp.: 3 Hz-1 kHz (±1 dB)
5. Body: 316L stainless, IP67, salt-spray proof for offshore
6. Mounting: M8 stud + 360° swivel head—no extra bracket needed
Quick Snapshots
|
Application
|
Location
|
Benefit
|
|
Offshore water-injection pump
|
Motor DE
|
Detected outer-race crack 3 weeks earlier
|
|
District heating circulation pump
|
Pump head
|
Zero complaint by online switch-over
|
|
Wind-turbine gearbox
|
HSS housing
|
1 Hz cloud upload via SCADA
|
Wiring & Jumper Guide
1. Power: +24 V → term. 1, 0 V → term. 2
2. Loop: term. 3-4 wired to AI card, load ≤ 500 Ω
3. Raw accel.: BNC for portable analyzer & spectrum cross-check
4. Range shift: move J1 jumper under power-off, done in 5 s
Main Application Fields:
1. Power Generation: Turbine and generator condition monitoring
2. Petrochemical Industry: Compressor and pump vibration analysis
3. Steel Industry: Rolling mill bearing monitoring
4. Aerospace: Jet engine and gas turbine measurement
5. Paper & Cement Industry: Equipment operation protection
—— Need GSI124 CAD outline & wiring PDF? Mail ab@mooreplc.com, May delivers pack within 12 h ——
