Product Focus | Specs, Mounting & Why It Matters
What it is
The 200-595-046-414 base plate is the structural backbone of every VM600 condition-monitoring rack. Made from conductive-passivated aluminium, it provides 14 Euro-card slots, integrated power buses and rear I/O transition area — all in a 6 U × 19-inch frame only 300 mm deep.
Key parameters at a glance
|
Feature
|
Value
|
Note / Source
|
|
Slots
|
14 (4 HP pitch)
|
Accepts CPU, I/O, relay, power
|
|
Power buses
|
+5 V, ±12 V, +24 V
|
160 A aggregate, star-ground <10 mΩ
|
|
Rear I/O
|
96-pin Din-41612 A/B/C
|
Optional transition board
|
|
Material / finish
|
Al alloy, conductive passivation
|
0.62 kg, 96 h salt-spray
|
|
Operating temp
|
-20 … +70 °C
|
IEC 60068-2-1/2 verified
|
|
Vibration
|
5 g, 10-2000 Hz
|
Random, 30 min/axis
|
|
Depth
|
300 mm
|
Needs 50 mm side clearance only
|
Creative comparison---VM600 plate vs. universal 6 U sub-rack
|
Criteria
|
VM600 200-595-046-414
|
Generic 6 U sub-rack
|
|
Earth impedance
|
<10 mΩ (star)
|
>50 mΩ (daisy-chain)
|
|
Max current per slot
|
10 A continuous
|
3 A typical
|
|
Coding pins
|
Yes – prevents mis-insert
|
No
|
|
Salt-spray rating
|
1000 h (S-option)
|
96 h standard
|
|
Depth
|
300 mm (fits 600 mm cabinet)
|
350-400 mm
|
Plug-in & forget
Slots are keyed and coded – CPU, I/O or power modules slide in and lock without tools. Perforated walls accept a 200 mm fan tray, guaranteeing 1 m/s airflow across card edges, essential for >100 kS/s ADCs.
