General
|
|
|
Device Type
|
Switch
- 48 ports - managed
|
|
Enclosure Type
|
Rack-mountable
1U
|
|
Subtype
|
Fast
Ethernet
|
|
Ports
|
48
x 10/100 + 2 x combo Gigabit SFP
|
|
Performance
|
Switching
capacity: 32 Gbps ¦ Forwarding performance (64-byte packet size): 10.1 Mpps
|
|
MAC Address Table Size
|
8K
entries
|
|
Remote Management Protocol
|
SNMP
1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP,
HTTPS, TFTP, SSH
|
|
Encryption Algorithm
|
SSL
|
|
Authentication Method
|
Secure
Shell (SSH), RADIUS, TACACS+
|
|
Features
|
Layer
2 switching, auto-sensing per device, dynamic IP address assignment,
auto-negotiation, BOOTP support, ARP support, load balancing, VLAN support,
auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DiffServ
support, Broadcast Storm Control, IPv6 support, Multicast Storm Control,
Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, Multiple
Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking
Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access
Control List (ACL) support, Quality of Service (QoS), Link Aggregation
Control Protocol (LACP), Port Security, MAC Address Notification, Remote
Switch Port Analyzer (RSPAN)
|
|
Compliant Standards
|
IEEE
802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE
802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE
802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP)
|
|
RAM
|
64
MB
|
|
Flash Memory
|
32
MB flash
|
|
Status Indicators
|
Port
transmission speed, port duplex mode, power, link OK, system, link/activity
|
|
Expansion /
Connectivity
|
|
|
Interfaces
|
2
x 1000Base-T RJ-45 ¦ 48 x 100Base-TX RJ-45 ¦ 2 x SFP (mini-GBIC)
|
|
Power Device
|
Internal
power supply
|
|
Voltage Required
|
AC
120/230 V (50/60 Hz)
|
|
Power Consumption Operational
|
39
Watt
|
|
Rack Mounting Kit
|
Optional
|
|
MTBF
|
336,409
hours
|
|
Compliant Standards
|
TUV
GS, CISPR 22 Class A, GOST, BSMI CNS 13438 Class A, CISPR 24, NOM, VCCI Class
A ITE, EN55024, CB, EMC, MIC, IEC 60950-1, EN 60950-1, UL 60950-1 Second
Edition, RoHS, CSA C22.2 No. 60950-1, FCC Part 15 B Class A
|
|
Software Included
|
Cisco
LAN Base software
|
|
Width
|
17.5
in
|
|
Depth
|
13
in
|
|
Height
|
1.7
in
|
|
Weight
|
8
lbs
|
|
Power
|
|
|
Service & Support
|
Limited
warranty - lifetime
|
|
Min Operating Temperature
|
23
°F
|
|
Max Operating Temperature
|
104
°F
|
|
Humidity Range Operating
|
10
- 95% (non-condensing)
|
|
Min Storage Temperature
|
-13
°F
|
|
Max Storage Temperature
|
158
°F
|
|
Humidity Range Storage
|
10
- 95% (non-condensing)
|
