WS-C6504-E Overview
The Cisco Catalyst WS-C6504-E Chassis is a 320-Gbps, small form factor, high-performance chassis. With the Cisco Catalyst 6500 Series Supervisor Engine 720, it can deliver up to 80 Gbps of switching capacity per slot. The 6504-E Catalyst switch offers the broadest range of interface modules with industry-leading performance and advanced feature integration.With this flexibility the Cisco Catalyst 6504-E is suitable for deployments ranging from small and medium-sized core networks to distribution and access networks and to the WAN edge. With high availability and resiliency the platform is well suited for metro provider-edge applications.The 4-slot Cisco Catalyst 6504-E Chassis delivers performance in a compact 5-rack-unit (5-RU) form factor. It can be configured two ways-with a single supervisor engine and up to three line cards, or with dual supervisor engines and up to two line cards. The Cisco Catalyst 6504-E also supports redundant AC or DC power supplies.
WS-C6504-E Specification
|
Technical
Specifications
|
|
|
General
|
|
|
Device Type
|
Switch
|
|
Enclosure Type
|
Rack-mountable
5U
|
|
Features
|
Modular
design
|
|
Expansion /
Connectivity
|
|
|
Expansion Slots
|
4
(total) / 4 (free) x expansion slot
|
|
Installed Modules Qty (Max)
|
0
(installed) / 4 (max)
|
|
Miscellaneous
|
|
|
MTBF
|
7
years
|
|
Compliant Standards
|
NEBS
level 3, FCC Class A certified, CISPR 22 Class A, EN 60950, EN 61000-3-2,
VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL
60950, EN50082-1, AS/NZS 3260, AS/NZ 3548 Class A, EMC, FCC Part 15, CSA
C22.2 No. 60950-00, ICES-003 Class A
|
|
Software /
System Requirements
|
|
|
OS Required
|
Cisco
IOS 12.2(18)SXE
|
|
Dimensions
& Weight
|
|
|
Width
|
17.5
in
|
|
Depth
|
21.7
in
|
|
Height
|
8.7
in
|
|
Weight
|
39.9
lbs
|
|
Environmental
Parameters
|
|
|
Min Operating Temperature
|
32
°F
|
|
Max Operating Temperature
|
104
°F
|
|
Humidity Range Operating
|
10
- 85%
|
|
Warranty
|
1
year
|
|
Lead time
|
2-3
business days
|
