WS-G5484 Overview
The Cisco 1000BASE-T Gigabit Interface Converter (GBIC) is an ideal solution for Catalyst ® 6500, 4000, 3550, 2950, 3500 XL and 2900 XL Series switch customers, providing full duplex Gigabit Ethernet connectivity to high-end workstations and between wiring closets over existing copper network infrastructures. This GBIC technology leverages the industry’s flexible, standards-based 1000BASE-X design, allowing for a simple and low-cost migration path to Gigabit Ethernet. There are two key product applications for the Cisco 1000BASE-T GBIC: connectivity to high-end workstations and distribution and wiring closet interconnectivity.
The Cisco 1000BASE-SX GBIC (WS-G5484) operates on legacy multimode fiber (MMF) optic link spans up to 1815 feet (550 m) and on laser-optimized multimode fiber (OM3) optic link spans up to 3281 feet (1 km).
WS-G5484 Specification
|
Product Number
|
WS-G5484
|
|
Description
|
1000BASE-SX Short Wavelength GBIC (Multimode only)
|
|
GBIC
|
Cisco 1000BASE-SX
|
|
Wavelength (nm)
|
850
|
|
Fiber Type
|
MMF
|
|
Core Size
(Micron)
|
62.5
|
|
62.5
|
|
50
|
|
50
|
|
50
|
|
Modal
Bandwidth (MHz/km)
|
160
|
|
200
|
|
400
|
|
500
|
|
2000
|
|
Cable
Distance
|
722 ft (220 m)
|
|
902 ft (275 m)
|
|
1640 ft (500 m)
|
|
1804 ft (550 m)
|
|
3281 ft (1000 m)
|
