Φ3×20 High Frequency Chokes With Ferrite Rod Core Inductor

We can design rod core inductor with ferrite rod core, single layer winding with or without shrink tube, terminal tinned copper wire or LITZ wire, high resonance frequency.



Hefei Mycoil Technology Co., LTD produce various series rod core inductors and design as your requirements, our high frequency chokes rod core inductors are widely used in switching power supply, power amplifiers, broadband filtering, notebook computer, digital electronic products, buck converter, LCD and other electronic equipments.


Quick Details

PN: MCT Φ3×20 Rod core inductor

Brand Name: MCT

Current Rating: @50Hz and 40℃ Ambient temperature

Custom Made: Available

Inductance Tolerance:±20%

Logo: Can be customized

Normal Inductance: Measure at 25℃

Packing: Carton,can custom

Testing Current: 0.1mA

Certification: ISO9001,ROHS,CE

Testing frequency :L≤10uH:1MHz,10uHL≤1000uH:100KHz,L1000uH:10KHz

OEM: Available

Climate level: 40/125/56

Lead Time: 25 days after payment

Terminal Tinned Copper Wire or LITZ Wire

MOQ: Any quantity

Ferrite Rod Core

Shipping: Air, Ship, etc

Single Layer Winding

With or Without Shrink Tube

Dimension Tolerance: Component:±0.5mm   Terminal±2.0mm

High Resonance Frequency


Part Information

Product Name: High Frequency Chokes With Ferrite Rod Core Inductor

Applications: switching power supply, power amplifiers, broadband filtering, digital electronic products.

Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray

Samples time: 7-10 days for customized parts, 3-5 days for standard parts.

Advantages:Our factory is made up of 500 people, huge output can be finished every day.

We have a technical team consist of 5 experienced engineers.

All materials are environmental protected. We accept custom made and design service.


Product Specification

High Frequency Chokes with Ferrite Rod Cores  Φ3×20

IR in A

LR in uH

RDC-mΩ

ΦC-mm

MCT PN

1.0

27

70

0.40

MCT-LB-A01

2.0

12

25

0.60

MCT-LB-A02

3.0

7

15

0.75

MCT-LB-A03

4.0

5

10

0.85

MCT-LB-A04


We can supply these dimension Ferrite Rod Core.Please make your design with the following table:

Type

Diameter:A

Length:B

Type

Diameter

Length

R1.65×7

1.65±0.20

7±0.40

R6×10

6±0.30

10±0.40

R1.65×10

1.65±0.20

10±0.40

R6×12

6±0.30

12±0.40

R2×7

2±0.20

7±0.40

R6×15

6±0.30

15±0.40

R2×10

2±0.20

10±0.40

R6×20

6±0.30

20±0.40

R3×10

3±0.20

10±0.40

R6×22

6±0.30

22±0.50

R3×12

3±0.20

12±0.40

R6×22.5

6±0.30

22.5±0.50

R3×14

3±0.20

14±0.40

R6×25

6±0.30

25±0.50

R3×15

3±0.20

15±0.50

R6×30

6±0.30

30±0.50

R3×16

3±0.20

16±0.50

R6×45

6±0.30

45±0.50

R3×20

3±0.20

R6.2×26

6.2±0.30

26±0.50

R4×10

4±0.20

10±0.40

R7.94×7.94

7.94±0.30

7.94±0.40

R4×11

4±0.20

R8×18.5

8±0.40

18.5±0.50

R4×12

4±0.20

12±0.40

R8×20

8±0.40

20±0.50

R4×15

4±0.20

15±0.50

R8×25

8±0.40

25±0.50

R4×16

4±0.20

16±0.50

R8×30

8±0.40

30±0.50

R4×18

4±0.20

18±0.50

R8×32

8±0.40

32±0.50

R4×19

4±0.20

19±0.50

R8×40

8±0.40

40±0.50

R4×20

4±0.20

20±0.50

R10×6

10±0.50

6±0.40

R4×25

4±0.20

25±0.50

R10×12

10±0.50

12±0.40

R4.5×19

4.5±0.20

19±0.50

R10×20

10±0.50

20±0.50

R5×4

5±0.20

4±0.40

R10×22

10±0.50

22±0.50

R5×10

5±0.20

10±0.40

R10×30

10±0.50

30±0.50

R5×12

5±0.20

12±0.40

RWW3×8

3±0.20

8±0.40

R5×13

5±0.20

ROO3×10

3±0.20

10±0.40

R5×15

5±0.20

15±0.50

ROO4×15

4±0.20

15±0.50

R5×18

5±0.20

18±0.50

RWW4×20

4±0.20

20±0.50

R5×20

5±0.20

20±0.50

ROO5×15

5±0.30

15±0.50

R5×21.5

5±0.20

21.5±0.50

ROO5×20

5±0.30

20±0.50

R5×24

5±0.20

24±0.50

R5×25

5±0.20

25±0.50

R5×30

5±0.20

30±0.50

R5.5×17

5.5±0.20

17±0.50
