1.25G DWDM 40KM SFP TRANSCEIVER

This is a SM module,the Data-rate of 1.25Gbps operation and the wavelength is 1528.77~1563.86nm,maximum transmission distance is up to 40KM.



ESDXX24-3LCD40

2.67Gbps DWDM SFP Optical Transceiver, 40KM Reach


Features

Ø  Wavelength selectable to C-band ITU-T grid wavelengths

Ø  Suitable for use in 100GHz channel spacing DWDM systems

Ø  DWDM SFP MSA Compliant

Ø  Dual data-rate of 2.67Gbps/1.25Gbps/1.063Gbps operation

Ø  OC-48 40KM range

Ø  Up to 2.67Gb/s data rate

Ø  Cold Start up Wavelength Compliance

Ø  Low Power Dissipation <1.3W Maximum

Ø  -5ºC to 70ºC Operating Case Temperature

Ø  Diagnostic Performance Monitoring of module temperature,

Supply Voltages, laser bias current, transmit optical power,

Receive optical power, Laser temperature and TEC current

Ø  Extended link budget with APD receiver technology

Ø  RoHS compliant and lead free


Applications

Ø  SFP Transceivers for DWDM SONET/ SDH

Ø  Ethernet IEEE 802.3ae

Ø  Fiber Channel


Description

ETU-Link DWDM SFP Transceiver exhibits excellent wavelength stability, supporting operation at 100GHz channel, cost effective module. It is designed for DWDM SONET/ SDH, Gigabit Ethernet and Fiber-Channel applications.

The transceiver consists of two sections: The transmitter section incorporates a colded DFB laser. And the receiver section consists of a APD photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. ETU-Link DWDM SFP transceiver provides an enhanced monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage, laser temperature and TEC current.
