Specification

LIGHT SOURCE

Lamp: Lamp: 36pcs*10W  RGBW 4 in 1 LED

Lifespan: 50,000H

OPTICS

Beam angle: 15°～60° zoom

COLORS

RGBW linear color mixing；color change controlled in independent groups, create chasing effect; built-in macros function

MOVEMENT
Pan movement: 540° optional (16 bit )

Tilt movement: 270°(16 bit )
Advanced moving system: auto repositioning, fast, quiet and smooth

FEATURES

Dimmer: 0-100% linear electronic dimmer

Strobe: 1-25Hz or random

Electronic dimming, color strobe effect

General dimming and blackout for all colors

Perfect pulse and rainbow effect

Smooth RGBW color mixing

Full Master/Slave operation in any operational mode

Low heat and long life LED (100,000H)

Flicker free.

SOFTWARE

Control mode: DMX512, master-slave, auto-run, sound activate

Channel: 10/14 CH

OTHER SPEC

Fixture and lamp usage time display

Highly positioning precision

Adjustable fan speed

Built-in analyzer for easy fault finding, error messages

Input signal isolating protection

Auto thermal protection circuit

Housing: high temperature UV resistant ABS

POWER
Voltage: AC100-240V, 50/60Hz

Power Consumption: 420W@220V

DIMENSIONS AND WEIGHT
Fixture dimension: 35x23x44cm

Packing dimension:

                              39x31x46cm(Carton)

                           70x33x63cm(2 in 1 flightcase)

                               85x53x66cm(4 in 1 flightcase)

Net Weight:           9.5kg

Gross Weight:

                           12kg(Carton)

                               43kg(2 in 1 flightcase)

                               74kg(4 in 1 flightcase)
