Specification
LIGHT SOURCE
Lamp: Osram 19pcsx15W RGBW 4in 1 LED
Lifespan: 50,000H
OPTICS
High precision glass optic system
Zoom: 4-60°
COLORS
RGBW linear color mixing
Color change controlled in independent
groups, each bead can be independently controlled
Unique honeycomb-shape lens can
limitlessly rotate, making multiplex dream-like effects
Bult-in macro function
MOVEMENT
Pan movement: 540° optional (16 bit )
Tilt movement: 270°(16 bit )
Advanced moving system: auto repositioning, fast, quiet and smooth
FEATURES
Function: wash, beam, FX effects
Zoom: 4°-60°
Dimmer: 0-100% linear electronic dimmer
Strobe: 1-25Hz or random
Individual LED control
Beam edge softening control for wash mode
Pixel Patterning macros with enhanced
control
Adjustable speed stop/strobe effect, with
instantaneous blackout
White CT Emulation 2500-8000K
RGBW auto-tuning to lamp CT Emulation
Exclusive parallel beam consisting of
an array of individually controllable micro-beams
Enhanced electronic engine for dynamic
beam pattern design, with digital accuracy and repeatability
Bi-directional rotating front lens countless vortex effects, aerial or
"kaleidoscopic" projection use
Digital wash beam framing effect
DISPLAY
2.8 inch full color touch LCD screen, show
customer logo
15 second standby auto lock
SOFTWARE
Control mode: DMX512, master-slave,
auto-run, sound activate
Channel: 23CH/21CH（Standard/35CH(Image)/78CH(Extensible)/97CH(RGBW Extensible)/92CH(Full)
OTHER SPEC
Fixture and lamp usage time display
Highly positioning precision
Adjustable fan speed
Built-in analyzer for easy fault finding,
error messages
Input signal isolating protection
Auto thermal protection circuit
Housing: high temperature UV resistant ABS
POWER
Voltage: AC100-240V, 50/60Hz
Power Consumption: 450W@220V
DIMENSIONS AND WEIGHT
Fixture dimension: 45x30x43cm
Packing dimension:
54x42x49cm(Carton)
75x42x85cm(2 in 1 flightcase)
Net Weight: 18kg
Gross Weight:
20kg(Carton)
58kg(2 in 1 flightcase)
