Allen-Bradley 2094-BC04-M03-S Kinetix 6000 Multi-Axis Servo Drive – Compact & Efficient Motion Solution
Released by Sales Manager May | 20 years of automation distribution experience
E-mail: ab@mooreplc.com | Phone/WhatsApp: +86-18106909650 | WeChat: dcsfcs
1. Product Snapshot
The 2094-BC04-M03-S is a 400 V-class Kinetix 6000 Integrated Axis Module (IAM) that integrates a 28 kW three-phase rectifier and a 30 A peak inverter in a slim 100 mm book-style chassis.
It serves as the “front end” of a multi-axis SERCOS servo system: one shared DC-bus can feed up to eight additional Axis Modules (AM), letting you build an entire machine without extra transformers or contactors.
2. Key Electrical Data
|
Item
|
Value
|
|
Input voltage
|
324…528 V rms 3-ph, 47–63 Hz
|
|
Continuous power
|
28 kW
|
|
DC-bus output
|
650…750 V DC nominal
|
|
Inverter output
|
15 A cont. / 30 A peak (2 s) @ 460 V
|
|
Overload
|
200 % with Peak-Enhance firmware
|
|
Built-in shunt
|
200 W cont. / 18 kW peak
|
|
Control supply
|
24 V DC ±10 %, 1 A
|
|
Communication
|
SERCOS fibre ring, 4 or 8 Mbps
|
3. Mechanical & Environmental Specifications
|
Item
|
Specification
|
|
Width
|
100 mm (4 in.)
|
|
Depth
|
275 mm (10.8 in.)
|
|
Vibration
|
5 g, 10…500 Hz
|
|
Operating temp
|
0…50 °C (derate above 45 °C)
|
|
Certifications
|
UL, c-UL, CE, RCM, TÜV STO SIL3/PL-e
|
4. Typical 4-Axis System Bill of Materials
|
Qty
|
Part Number
|
Description
|
|
1
|
2094-BC04-M03-S
|
Integrated Axis Module (IAM)
|
|
3
|
2094-BM03-S
|
Axis Module (AM), 30 A peak
|
|
1
|
2094-PR8
|
8-slot power rail
|
|
1*
|
2094-BSP2
|
External shunt resistor (*if needed)
|
|
1
|
1756-L8x + 1756-M08SE
|
Controller & SERCOS module
|
5. Competitive Advantages – Why Engineers Still Choose Kinetix 6000
· Shared DC-bus recycles braking energy to neighbouring axes; no line-regen required on most machines.
· Peak-Enhance firmware delivers 200 % torque for 2 s without oversizing the supply—ideal for indexers and fast quill moves.
· Uniform 100 mm width covers 4 A…49 A modules; one spare fits all, keeping panels clean.
· Full Studio 5000 integration: one-click auto-tune, load observer, single-tag access to torque, velocity and position loops.
6. Price & Availability
Stocked in Xiamen with a 12-month warranty.
Need it tomorrow? Confirm PO & payment before 4 p.m. China time and we ship DHL the same day.
For quotations,contact May:
E-mail: ab@mooreplc.com | WhatsApp: +86-18106909650 | WeChat: dcsfcs
Let our 20 years of Allen-Bradley motion experience shorten your commissioning calendar.
