PEEK insulated wires with Silver-plated or Nickel-plated conductors
Key Features
Halogen free and low toxicity
Excellent radiation resistance
PEEK cable outstanding and excellent abrasion resistance, dielectric strength, chemical resistance, thermal endurance in long. protects against corrosion
CITCABLE can make a crystalline, A semi-crystalline, non-crystalline peek wire cables, PEEK offers excellent mechanical properties and chemical resistance coupled with outstanding thermal and combustion characteristics Typical applications include nuclear power wiring, chemical processing, and ultrahigh vacuum (UHV) environments,PEEK insulated wire is available by custom order and in crystalline and amorphous; we can extrude this material in round, square. We can also provide PEEK insulated wire in stranded and other wire
CITCABLE: 260°C Flat Duplex PEEK insulated thermocouple wire
Features of PEEK WIRE
1. No halogen content, Low outgassing Low elution,
2. Low toxic-gas content ,High heat resistance (260℃)
3. Flame resistance (UL94-V0,UL VW-1,FT6)
4. Radiation resistance High sliding performance
CITCABLE provide flat duplex PEEK insulated thermocouple wire consisting of a pair of conductors individually PEEK/PAEK insulated, and then PEEK Jacket sheathed. In response to the needs of many of our customers.
CITCABLE provide Types K and T, with 0.2mm,0.254mm, 0.32-mm and 0.65-mm conductors, respectively. CITCABLE can also make products compliant with Class 1 and Class 2 and OHTERS ,We can also make PEEK insulated, heat resistant wire.
