1. Quick Facts – Table
|
Item
|
Specification
|
|
Part number
|
IS200WETBH1ABA (ABA = revision suffix)
|
|
Series
|
Mark VI / VIe
|
|
Function
|
16-channel TC input, isolated, software-selectable J/K/T/E/S/R/N/B
|
|
Field terminals
|
48 rising-clamp, max. 2.5 mm², accepts TC extension wires directly
|
|
Cold-junction compensation
|
On-board RTD, ±0.5 °C accuracy
|
|
Isolation
|
1 000 V rms channel-to-ground & channel-to-channel
|
|
Surge
|
IEC 61000-4-5 2 kV common-mode
|
|
Operating temp.
|
–25 … +70 °C
|
|
Certifications
|
CE, UL, RoHS
|
2. Key Features & Application – Table
|
Feature
|
Benefit / Application
|
|
Direct plug-in to Mark VIe carrier
|
Eliminates external marshalling, saves wiring time
|
|
Open-circuit & reverse-polarity detection per channel
|
Immediate fault location, reduces downtime
|
|
Integrated shield-ground bar
|
Enhanced noise immunity for long TC runs
|
|
On-board CJ RTD
|
±0.5 °C accuracy, no external ice-point needed
|
|
Exhaust-gas, steam-chest, blade & HRSG duct temperature loops
|
Typical turbine/compressor monitoring points
|
3. Compatible I/O Packs
IS200TBTCH1C – 16-ch TC input pack (preferred)
IS200TBTCH2A – high-speed version (50 ms scan)
4. Typical Wiring
Positive TC wire → channel terminal
Negative TC wire → return terminal
Shield → ground bar provided
5.Standardized Service Process
5-Step Procurement Guarantee:
Technical Confirmation: Provide detailed product parameter comparison tables to ensure compatibility.
Price Negotiation: Enjoy bulk purchase discount tiers for cost efficiency.
Contract Signing: Support T/T payment and secure transaction processing.
Professional Packaging: Multi-layer shock-proof protection for safe shipping.
After-Sales Support: Free replacement within 12-month warranty period.
